3. Time set mode, (Press ENTER key can escape Time set mode) = = : = =
= =is displayed in third display. Time (hours, minutes, seconds) value is
entered via overlay numbers, then press overlay ENTER key. Time start
from set time value and exit set mode.
T1/T2 T1-T2 second display Input Selection
The input selection indicates which input is selected for second display; T1
thermocouple, T2 thermocouple or the difference between the two thermo-
couples (T1-T2), when the thermometer is turn on, it is set to T2 input can
select alternate of thermocouple by second display TYPE key switch.
K/J/T/E/R/S/N T2 Input Thermocouple Type Select (Second
display)
The TYPE key switch the T2 input circulating selects the K/J/T/E/R/S/N type
thermocouple as input, when second display input selected T2.
When the thermometer is turned on, it is set to the type selected that was
in use when the thermometer was last turned off.
" " Button
Press " " button to toggle on and off of backlight. The backlight will switch-
off automatically after 60 seconds.
