Technical data of the CT SB2
5 Technical data of the CT SB2
5.1 Specifications
5.2 Environmental conditions
5.3 Mechanical data
Table 5-1: CT SB2 specifications
Characteristic Rating
Mains connection Connector according to IEC 60320
Mains voltage 100 - 240V
AC
/ 50/60Hz / 0.2A
Mains fuses 2 x T2.0AH 250V (high-breaking capacity wire fuse 5 x 20mm)
Output voltage 0 - 120V
Table 5-2: Environmental conditions
Characteristic Rating
Operating temperature –10 … +50 °C (14 … 122 °F)
Storage and transportation –20 … +70 °C (–4 … 158 °F)
Max. altitude for operation 2000m
Table 5-3: Mechanical data
Characteristic Rating
Weight 2.6kg (5.7lbs) without accessories
Dimensions W x H x D 285 x 68 x 225mm (11.2 x 2.7 x 8.9")
