4
Ⅱ.Technical parameters:
Ⅲ.Packing list
Name
Quantity
Motor
1
Instruction Manual
1
Transmitter
2
Base plate
1
Screw (M8×30) ,washer, Nut
4
Limit switch magnet
2
Bracket for limit switch
2
Release Key
1
Expansion Bolt(M12×100)
4
Model
DCK-658
DCK-668
DCK-678
Power supply
(Vac)
AC Single-phase
110V/220V~240V
AC Single-phase
110V/220V~240V
AC Single-phase
110V/220V~240V
Max. gate weight
(KG)
500
800
1200
Max.torque
18Nm
22Nm
35Nm
Rated Power (W)
370W
450W
550W
Tooth number of
gear
15
15
15
Overheat protection
(℃)
120
120
120
Protection Class
IP44
IP44
IP44
Speed (m/min)
12
12
12
Temperature (
℃
)
–45
~+
65
–45
~+
65
–45
~+
65
Noise
≤56dB
≤56dB
≤56dB
Certification
CCC/CE
CCC/CE
CCC/CE
