Omnex T110c - T110 Label and Output Types; Some Available Output Types

T110 Configuration and Options 6 of 8
Ph# 1-800-663-8806
www.omnexcontrols.com
Function Name
As it will appear on the label
Button #
Safety Interlock
Button # to be
interlocked with
Type of Output
Select from above
Example: Momentary switch to 12 VDC
1
2
3
4
5
6
7
8
9
10
Shift + 1
Shift + 2
Shift + 3
Shift + 4
Shift + 5
Shift + 6
Shift + 7
Shift + 8
Shift + 9
Shift + 10
T110 Label and Output Types
Some Available Output Types
Momentary—Output is on while button is pressed.
Momentary Interlocked—A pair of momentary outputs; only one may be on at a time.
Latching— Pressing the button the first time turns on the output, the second press turns off the output.
Two Button Latching—Two buttons one output. ON button turns on output, OFF button turns off output.
Interlocked Latching—A pair of latching outputs; only one output can be on at a time. With an output ON, pressing the opposite but-
ton does nothing.
Toggled Interlocked Latching—A pair of latching outputs; only one output can be on at a time. With an output ON, pressing the op-
posite button turns off output.
Ramping Proportional—A pair of buttons used to increase and decrease a proportional output. Similar to the volume control on a
TV. Discuss options with your sales representative.
If any other output type is required please describe below or in the special requirements on page 7.
