Omnimount PLAY40 User Manual

PN:888-45-222-W-02: 45-284-026: OM1100549
STEP 1 - Wood Stud Installation
1
2
a
a
b c
Wood Stud Mount
c d
4x
W-A
W-B
1
b
7/32 x 2.75"
5.5mm x 70mm

Omnimount PLAY40 Specifications

General

Mounting type	Wall
Maximum VESA mount	600 x 400 mm
Minimum VESA mount	200 x 100 mm
Maximum screen size	55 \
Minimum screen size	30 \
Maximum weight capacity	18.2 kg
Pan range	0 - 180 °
Tilt angle range	-15 - 10 °
Product color	Aluminium, Black
Manual	Yes
