Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Please note: This fuse is being used for both 115 V and 230 V.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rearpanel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
10. TECHNICAL SPECIFICATIONS
Power supply: 115/230 V AC, 50/60 Hz ~
Power consumption: 18 W
Inputs: 3 phono, 4 line, 3 aux, 2 mic
Minimum input voltage: Microphone:
3 mV RMS, 10 kOhms
Phono: 1.2 mV RMS, 47 kOhms
Line: 78 mV RMS, 10 kOhms
Output voltage:
Line: 9 V RMS max.
Headphones: 0.5 V
Outputs: 2 Master-Out, 1 Rec-Out, 1 Booth-Out via RCA; Faderstart
Master 1 Out: via 2 additional, balanced XLR-connectors
Frequency range:
Microphone: 40 - 15,000 Hz, ± 0.5 dB
Phono: 20 - 20,000 Hz, ± 1 dB
Line: 20 - 20,000 Hz, ± 0.5 dB
Distortion: < 0.01 %
S/N-ratio:
Microphone: > 80 dB
Phono: > 78 dB
Line: > 88 dB
Talkover-attenuation: -15 dB
Tone control:
Treble: 20 Khz -30 dB to +15 dB
Middle: 1.2 KHz -30 dB to +15 dB
Bass: 40 Hz -30 dB to +15 dB
Dimensions (WxDxH): 482 x 241 x 92 mm
Weight: 4.8 kg
Fuse: F 0.5 A, 250 V
Please note: Every information is subject to change without prior notice. 03/02 ©
