Omnitronic EM-260B - Technical Specifications; Connector Configuration

19
7
TECHNICAL SPECIFICATIONS
EM
-
260
Power supply: 115/230 V AC, 50/60 Hz ~
Power consumption: 35 W
Inputs MIC 1-3: XLR/6.3 mm jack
Max. input level: -14 dB
Inputs LINE 1-3: stereo RCA
Max. input level: 24 dB
RETURN: 6.3 mm stereo jack
Outputs:
MASTER: 6.3 mm stereo jack
REC: stereo RCA
SEND: 6.3 mm jack
Tone control:
High: -12 dB to +12 dB/ 10 kHz
Bass: -12 dB to +12 dB/ 100 Hz
Distortion: 0.025 %
S/N ratio: 69 dB
Dimensions (WxDxH): 482 x 123 x 43 mm (19", 1 U)
Weight: 2.2 kg
Specifications are subject to change without notice due to product improvements
Connector Configuration
