23
6.3 mm jack for connecting stereo headphones
24
Gain controls for the input amplification of phono inputs 1 and 2
25
Ground clamping screw for turntables
26
Balanced XLR output L/R for connecting a further amplifier, e.g. for the monitoring system or
PA application in a secondary room
27
Balanced XLR output L/R for connecting an amplifier or other units with line level input
28
Stereo inputs (RCA) for channel 1 and 2 for connecting units with line level outputs such as CD
players (LINE 1-4) or turntables with magnetic system (PH 1, 2)
29
Stereo output (RCA) for connecting a recording unit
30
Stereo output (RCA) for connecting a further amplifier, e.g. for the monitoring system or PA
application in a secondary room
31
Stereo output (RCA) for connecting an amplifier or other units with line level input
32
Power on/off
33
Input for the included power unit
..............................................................................................................................................................................
TECHNICAL SPECIFICATIONS
TRM
TRMTRM
TRM-
--
-202
202202
202
MK2
MK2MK2
MK2
Power supply: 230 V AC, 50 Hz via supplied power unit
Power consumption: 18 W
Inputs:
LINE: 4 x RCA L/R
PHONO: 2 x RCA L/R
DJ MIC: XLR
Tone control: -~ to +6 dB (highs, lows)
Outputs:
MASTER: XLR/RCA L/R
BOOTH: XLR/ RCA L/R
REC: RCA L/R
Headphones: 6.3 mm jack (min. 32 ohms)
Frequency isolator:
Lows: 20 Hz - 300 Hz
Mids: 300 Hz - 4 kHz
Highs: 4 kHz - 20 kHz
Frequency range: 20-20000 Hz
Dimensions (WxDxH): 235 x 190 x 90 mm
Weight: 3 kg
