OMP Hobby Edge 540 - Page 5

LandinggearAssembly
Ø LandingGearInstallation
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
5. Slidethecuffsoverthelandinggearandsecurewithscrews.
Becarefultonotbreakthescrews.Ifthescrewseemstobe
difficulttoinsertuseadrilltoopenupthehole.(Some
peoplehavefoundtheypreferadobofsiliconeinsidethe
cuffholdthemsecure.)
2. Unscrewhexagonscrewsonthelandinggearplate.
3. Applygluetohexagonscrews,useittosecurethe
carbonfiberlandinggeartolandinggearplate.
4. Putlandinggearcoverplateintoaslotandstickit
withtransparenttape.
1. Landinggearpartscontentsareshownbelow.
