OMP Hobby M2 Evo - Assembly Step 12: Flight and Servo Settings; Flight Parameter Adjustment Guide; Servo Neutral Position Calibration

step 12 步骤十二
󲒐
Antenna
LED Light
尾电机线接口
对频按键
主电机线接口
电源线
飞行参数设置说明
一般飞行模式
油门
螺距
5
60 100 12°
4
60 65
5.5°
3
60 15 1.8°
2
60
-5
-0.6°
1
0 -20 -2.4°
姿态模式/3D模式
模式
飞控LED
CH5
姿态模式
75-100
3D 模式
0-25
蓝灯常亮
红灯常亮
蓝灯常亮
红灯慢闪
IDLE 1模式
油门
螺距
5
65 100 11°
4
65 50
5.5°
3
65
5
0.6°
2
65 -50
-5.5°
1
65 -100 -11°
油门
螺距
5
80 100 11°
4
80 50
5.5°
3
80 0 0°
2
80 -50
-5.5°
1
80 -100 -11°
IDLE 2模式
通电自检/对频
状态
飞控LED
上电自检
需将M2放在平地上通电，通
电后蓝灯、红灯快闪，静止3
秒钟直到蓝灯常亮 .
对频前
对频后
蓝灯常亮
蓝灯慢闪
舵机中位调整
调试前请先断开主尾马达电源线，避免安全隐患！
1.打开遥控器电源，给飞机通电，飞机自检过后可以正常控制舵
机工作状态；
2.将油门摇杆放到最低，升降舵摇杆推到最高直到飞控LED红灯快
闪；
3.将油门摇杆推到最高，此时可以分别通过副翼、升降、方向摇
杆调整对应舵机中位；
4.将油门摇杆拉到最低，升降舵摇杆推到最高直到红灯慢闪或常
亮，舵机中点保存完成。
在更换舵机，飞控，需要重新检查舵机中点。
BIND
Tail Motor
LED灯
Main Motor
POWER
General Flight Model
IDLE 1 Model IDLE 1 Model
Throttle Screw Pitch Throttle Screw Pitch Throttle Screw Pitch
Flight Parameter Setting lntroduction
Attitude mode /3D mode
Power On Self Test / Binding
Servo Neutral Position Adjustment
Modes
Attitude Modes
3D Modes
Flight Control LED
Blue LED Steady Lit
Red LED Steady Lit
Blue LED Steady Lit
Red LED Slow Flash
Status
Flight Control LED
Power On Self Test
Before Binding
After Binding
The M2 should be placed on
the ground to be energized.
After power on,the blue and
red Led flash quickly and
wait for 3 seconds until the
blue Led is steady lit.
Blue LED Slow Flash
Blue LED Steady Lit
Please disconnect the main tail motor power cord before
debugging to avoid potential safety hazards!
1.Tum on the remote control and power on the aircraft.After the
aircraft self-test,the servo can be normally controlled;
2.Put the throttle stick to the lowest position and push the
elevator roker to the highest until the flight control LED
flashes red quickly;
3.Push the throttle stick to the hight position through the aileron,
lift and direction rocker respecively.
4.Push the throttle stick to the lowest position,and push the
elevator stick to the highest until the red Led flashes slowly or
conatanly,and the servo neutral position is saved.
󳋰󰵒
5V
󰭁󰤿
Data
3.3V
󰭁󰤿
Data
󳋰󰵒
CH1
CH2
CH3
17
EN
