Omron 3G3MX2-A2004-V1 Replacing Guide

21
6.2.
The difference of multi-function Input Settings
There are some difference of multi-function Input Settings between 3G3JX and 3G3MX2-V1. Before setting,
to refer the following list. Refer to related product user’s manuals.
3G3JX
3G3MX2-V1
Data No. Code Function name Code Function name
0 FW forward FW Forward
1 RV reverse RV Reverse
2 CF1
multi-step speed setting
binary 1
CF1
Multi-step speed setting
binary 1
3 CF2
Multi-step speed setting
binary 2
CF2
Multi-step speed setting
binary 2
4 CF3
multi-step speed setting
binary 3
CF3
Multi-step speed setting
binary 3
5 CF4
multi-step speed setting
binary 4
CF4
Multi-step speed setting
binary 4
6 JG jogging JG Jogging
7 DB external DC injection braking DB External DC injection braking
8 SET 2nd control SET 2nd control
9 2CH
2-step
acceleration/deceleration
2CH
2-step
acceleration/deceleration
11 FRS free-run stop FRS Free-run stop
12 EXT external trip EXT External trip
13 USP USP function UPS
Power recovery restart
prevention function
14 - - CS Commercial switching
15 SFT soft lock SFT Soft lock
16 AT analog input switching AT Analog input switching
18 RS reset RS Reset
19 PTC thermistor input TH
PTC thermistor thermal
protection
20 STA 3-wire start STA 3-wire start
21 STP 3-wire stop STP 3-wire stop
22 F/R 3-wire forward/reverse F/R 3-wire forward/reverse
23 PID PID enabled/disabled PID PID disabled
24 PIDC PID integral reset PIDC PID integral reset
27 UP
UP/DWN function
accelerated
UP
Remote operation
accelerated
28 DWN
UP/DWN function
decelerated
DWN
Remote operation
decelerated
29 UDC UP/DWN function data clear UDC Remote operation data clear
31 OPE forced operator OPE Forced operator function
50 ADD frequency addition ADD Set frequency A145 addition
