26
Output voltage gain 104Eh A045 123Fh A045
2nd output voltage gain 1514h A245 223Fh A245
DC injection braking
selection
1051h A051
00: Disabled
01: Enabled during stop
02: Output frequency<A052 DB
00: Disabled
01: Enabled
02: Enabled (Operates only at set
frequency)
DC injection braking
frequency
1052h A052 0 ~ 600 0.1[Hz] 1246h A052 0~6000 0.01[Hz]
DC injection braking delay
time
1053h A053 0 ~ 50 0.1[s] 1247h A053 0~50 0.1[s]
DC injection braking power 1054h A054 0 ~ 100 1[%] 1248h A054 0~100 (70) 1[%]
DC injection braking time 1055h A055 0 ~ 600 0.1[s] 1249h A055 0~600 0.1[s]
DC injection braking method
selection
00: Edge operation
01: Level operation
00: Edge operation
01: Level operation
-
124Fh A061(HIGH)
1250h A061(LOW)
224Fh A261(HIGH)
2250h A261(LOW)
1251h A062(HIGH)
1252h A062(LOW)
2251h A262(HIGH)
2252h A262(LOW)
1253h A063(HIGH)
1254h A063(LOW)
1256h A065(HIGH)
1257h A065(LOW)
1259h A067(HIGH)
125Ah A067(LOW)
Jump frequency width 1 105Eh A064 1255h A064
Jump frequency width 2 1061h A066 1258h A066
Jump frequency width 3 1064h A068 125Bh A068
PID selection 1068h A071
00: Disabled
01: Enabled
- 125Fh A071
00: Disabled
01: Enabled
02: Enabled (Reverse output
enabled)
PID P gain 1069h A072 2 ~ 50 0.1 1260h A072 0~2500 0.01
PID I gain 106Ah A073 0 ~ 1500 0.1[s] 1261h A073 0~36000 0.1[s]
PID D gain 106Bh A074 0 ~ 1000 0.1[s] 1262h A074 0~10000 0.01[s]
PID scale 106Ch A075 1 ~ 9999 0.01 1263h A075 1~9999 0.01
PID feedback selection 106Dh A076
00: Feedback (FI)
01: Feedback (FV)
02: External communication
10: Operation function output
00: Current (FI)
01: Voltage (FV)
02: Modbus communication
03: Pulse train frequency
10: Operation function output
Reverse PID function 106Eh A077
00: OFF (Deviation = Target value -
Feedback value)
01: ON (Deviation = Feedback value
- Target value)
00: Disabled (Deviation = Target
value − Feedback value)
01: Enabled (Deviation = Feedback
value Target value)
PID output limit function 106Fh A078 0 ~ 1000 0.1[%] 1266h A078 0~1000 0.1[%]
00: Always ON
01: Always OFF
02: OFF during deceleration
00: Always ON
01: Always OFF
02: OFF during deceleration
AVR voltage selection 1071h A082
200-V class
0: 200/ 1: 215/ 2: 220/ 3: 230/ 4:
240
400-V class
0: 380/ 1: 400/ 2: 415/ 3: 440/ 4:
460/ 5: 480
200-V class:
00 (200)/ 01 (215)/ 02 (220)/ 03
(230)/ 04 (240)
400-V class:
05 (380)/ 06 (400)/ 07 (415)/ 08
(440)/ 09 (460)/ 10 (480)
RUN mode selection 1072h A085
00: Normal operation
01: Energy-saving operation
00: Normal operation
01: Energy-saving operation
1073h A086 0 ~ 1000 0.1[%] 126Eh A086 0~1000 0.1[%]
1074h A092(MSB 1274h A092(HIGH)
1075h A092(LSB) 1275h A092(LOW)
1519h A292(MSB 226Fh A292(HIGH)
151Ah A292(LSB) 2270h A292(LOW)
1076h A093(MSB 1276h A093(HIGH)
1077h A093(LSB) 1277h A093(LOW)
151Bh A293(MSB 2271h A293(HIGH)
151Ch A293(LSB) 2272h A293(LOW)
2-step acceleration/
deceleration selection
2nd 2-step acceleration/
deceleration selection
1279h A095(HIGH)
127Ah A095(LOW)
2274h A295(HIGH)
2275h A295(LOW)
127Bh A096(HIGH)
127Ch A096(LOW)
2276h A296(HIGH)
2277h A296(LOW)
Acceleration pattern
selection
107Dh A097 127Dh A097
Deceleration pattern
selection
107Eh A098 127Eh A098
1281h A101(HIGH)
1282h A101(LOW)
1283h A102(HIGH)
1284h A102(LOW)
FI start ratio 1083h A103 1285h A103
FI end ratio 1084h A104 1286h A104
00: Line
01: S-shape curve
00: Line
01: S-shape curve
02: U-shape curve
03: Inverted U-shape curve
04: EL-S-shape curve
0~40000 (In the high-frequency
mode︓~58000)
2nd 2-step acceleration
frequency
2-step deceleration
frequency
2nd 2-step deceleration
frequency
2-step acceleration
frequency
0~40000 (In the high-frequency
mode︓~58000)
00: Switched via terminal 2CH
01: Switched by setting
00: Switch via 2CH terminal ( multi-
function input: 09)
01: Switch by setting( A095/ A295/
A096/ A296)
0~1000 (In the high-frequency
mode︓~10000)
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.0/Starting frequency
: b082 × 10 to Frequency upper
limit: A061 × 10
0~40000 (In the high-frequency
mode︓~58000)
0.0/Frequency lower limit
: A062 x 10 to Maximum frequency
: A004 x 10
0
1st Frequency Lower Limit to 1st
Maximum Frequency
0
Starting Frequency to 1st Maximum
Frequency
2nd frequency lower limit
0.0/Starting frequency
: b082 x 10 to 2nd frequency upper
limit: A261x10
0
Starting Frequency to 2nd Frequency
Upper Limit
2nd frequency upper limit
0.0/2nd frequency lower limit
: A262 x 10 to 2nd max. frequency
: A204 x 10
0
2nd Frequency Lower Limit to 2nd
Maximum Frequency
