Omron 3G3MX2-A2022-V1 Replacing Guide

27
FI start selection 1085h A105
00: Start frequency A101
01: 0 Hz
- 1287h A105
00: FI Start Frequency (A101)
01: 0 Hz
-
Operation frequency input A
setting
108Eh A141 12AFh A141
Operation frequency input B
setting
108Fh A142 12B0h A142
Operator selection 1090h A143
00: Addition (A + B)
01: Subtraction (A − B)
02: Multiplication (A × B)
- 12B1h A143
00: Addition (A141 + A142)
01: Subtraction (A141 − A142)
02: Multiplication (A141 × A142)
-
12B3h A145(HIGH)
12B4h A145(LOW)
Frequency addition direction 1093h A146
00: Adds the A145 value to the
output
- 12B5h A146
00: Frequency reference + A145
01: Frequency reference − A145
-
12C6h A161(HIGH)
12C7h A161(LOW)
12C8h A162(HIGH)
12C9h A162(LOW)
VR start ratio 1098h A153 0 ～ 100 1[%] 12CAh A163 0 to VR End Ratio 1[%]
VR end ratio 1099h A154 0 ～ 100 1[%] 12CBh A164 VR Start Ratio to 100 1[%]
VR start selection 109Ah A155 0, 1 - 12CCh A165
00: VR Start Frequency (A161)
01: 0 Hz
-
Retry selection 10A5h b001
00: Alarm
01: 0 Hz start
02: Frequency matching restart
03: Trip after frequency matching
deceleration stop
- 1301h b001
00: Trip
01: 0-Hz restart
02: Frequency matching restart
03: Trip after frequency matching
deceleration stop
04: Frequency pull-in restart
-
Allowable momentary power
10A6h b002 3 ～ 250 0.1[s] 1302h b002 3～250 0.1[s]
Retry wait time 10A7h b003 3 ～ 1000 0.1[s] 1303h b003 3～1000 0.1[s]
Momentary power
interruption/undervoltage
trip during stop selection
10A8h b004
00: Disabled
01: Enabled
- 1304h b004
00: Disabled
01: Enabled
02: Disabled during stop and
deceleration stop by turning off the
RUN command
-
Momentary power
interruption retry time
10A9h b005
00: 16 times
01: No limit
- 1305h b005
00: 16 times
01: No limit
-
Starting frequency at
frequency pull-in restart
1170h b011
00: Frequency at interruption
01: Max. frequency
02: Set frequency
- 131Fh b030
00: Frequency at interruption
01: Maximum frequency
02: Set frequency (Frequency
reference)
-
Electronic thermal level 10ADh b012 130Dh b012
2nd electronic thermal level 1527h b212 230Ch b212
Electronic thermal
characteristics selection
10AEh b013 130Eh b013
2nd electronic thermal
characteristics selection
1528h b213 230Dh b213
Overload limit selection 10B5h b021 1316h b021
2nd overload limit selection 1529h b221 2316h b221
Overload limit level 10B6h b022 1317h b022
2nd overload limit level 152Ah b222 2317h b222
Overload limit parameter 10B7h b023 1318h b023
2nd overload limit parameter 152Bh b223 2318h b223
Deceleration rate constant
1171h b029 1 ～ 30000 0.1[s] 131Eh b029 1～30000 0.1[s]
Frequency pull-in restart 1172h b030 200 ～ 20000 0.01[%] 131Dh b028 200～2000 0.1[%]
Soft lock selection 10BCh b031
00: Data other than b031 cannot be
changed when terminal SFT is ON.
01: Data other than b031 and the
specified frequency parameter
cannot be changed when terminal
SFT is ON.
02: Data other than b031 cannot be
changed.
03: Data other than b031 and the
specified frequency parameter
cannot be changed.
10: Data other than parameters
changeable during operation cannot
be changed.
- 1320h b031
00: Data other than b031 cannot be
changed when terminal SFT is ON.
01: Data other than b031 and the
set frequency cannot be changed
when terminal SFT is ON.
02: Data other than b031 cannot be
changed.
03: Data other than b031 and set
frequency cannot be changed.
10: Data can be changed during
RUN.
-
Selection of non-stop
function at momentary
power interruption
10C9h b050
00: Disabled
01: Enabled (Stop)
02: Enabled (Restart)
- 1334h b050
00: Disabled
01: Enabled (Deceleration stop)
02: Enabled (Constant voltage,
without recovery)
03: Enabled (Constant voltage, with
recovery)
-
Starting voltage of non-stop
function at momentary
power interruption
10CAh b051 0 ～ 10000 0.1[V] 1335h b051 0～10000 0.1[V]
Stop deceleration level of
non-stop function at
momentary power
interruption
10CBh b052 0 ～ 10000 0.1[V] 1336h b052 0～10000 0.1[V]
1337h b053(HIGH)
1338h b053(LOW)
Deceleration starting width
of non-stop function at
momentary power
interruption
10CEh b054 0 ～ 100 0.1[Hz] 1339h b054
0～1000 (In the high-frequency
mode︓10000)
0.01[Hz]
Overvoltage protection
proportional gain during
deceleration
1173h b055 2 ～ 50 0.1 1388h b133 0～500 0.01
Overvoltage protection
integral time during
deceleration
1174h b056 0 ～ 1500 0.1[s] 1389h b134 0～1500 0.1[s]
0.01[s]
1 ～ 300
0.1[s]
1～30000
0.1[s]
Deceleration time of nonstop
function at momentary
10CCh
b053
1 ～ 30000
0.1[s]
1～360000
00: Disabled
01: Enabled in acceleration/constant
-
00: Disabled
01: Enabled during
-
00: Disabled
01: Enabled in acceleration/constant
0.01[%]
200～2000
0.1[%]
0.01[Hz]
2000 to 10000
Set the rated current to 10000
0.01[%]
200～1000
0.1[%]
00: Reduced torque characteristics 1
01: Constant torque characteristics
02: Reduced torque characteristics 2
-
00: Reduced torque characteristics
01: Constant torque characteristics
02: Free setting
-
VR end frequency
1097h
A152
0 ～ 4000
0.1[Hz]
0～40000 (In the high-frequency
mode︓～58000)
0.01[Hz]
VR start frequency
1095h
A151
0 ～ 4000
0.1[Hz]
0～40000 (In the high-frequency
mode︓～58000)
0.01[Hz]
00: Digital Operator (F001)
01: Digital Operator (volume)
02: Input FV
03: Input FI
04: RS485 communications
-
00: Digital Operator (A020/A220)
01: Volume
02: Voltage (FV) input
03: Current (FI) input
04: Modbus communication
05: Option
07: Pulse train frequency
-
Frequency addition amount
1091h
A145
0 ～ 4000
0.1[Hz]
0～40000 (In the high-frequency
mode︓～58000)
