External Dimensions and Mounting dimensions
The following tables show external dimensions and mounting dimensions of 3G3JX and 3G3MX2-V1. You
can install multiple 3G3MX2-V1s side by side like 3G3JXs. Note that the external dimensions of
3G3MX2-V1 are smaller than or equal to 3G3JX but the depths (D) of all 3G3MX2-V1 models and the
heights (H) of over 5.5 kW models of 3G3MX2-V1 are larger than 3G3JX.
■ 3-phase 200-V class
*1
A2002 80 155 97.4 67 143 Φ5 A2002-V1 68 128 109 56 118 Φ4.5
A2004 80 155 111.4 67 143 Φ5 A2004-V1 68 128 122.5 0 0 Φ4.5
A2007 80 155 134.4 67 143 Φ5 A2007-V1 68 128 145.5 0 0 Φ4.5
A2015 110 189 159.4 98 176 Φ5 A2015-V1 108 128 170.5 0 0 Φ4.5
A2022 110 189 159.4 98 176 Φ5 A2022-V1 108 128 170.5 0 0 Φ4.5
A2037 110 189 159.4 98 176 Φ5 A2037-V1 140 128 170.5 0 0 Φ4.5
A2055 180 250 169.4 164 235 Φ6 A2055-V1 140 260 155 0 0 Φ6
A2075 180 250 169.4 164 235 Φ6 A2075-V1 140 260 155 0 0 Φ6
■ 3-phase 400-V class
A4004 110 189 132.4 98 176 Φ5 A4004-V1 108 128 143.5 96 118 Φ4.5
A4007 110 189 159.4 98 176 Φ5 A4007-V1 108 128 170.5 96 118 Φ4.5
A4015 110 189 159.4 98 176 Φ5 A4015-V1 108 128 170.5 96 118 Φ4.5
A4022 110 189 159.4 98 176 Φ5 A4022-V1 108 128 170.5 96 118 Φ4.5
A4037 110 189 159.4 98 176 Φ5 A4040-V1 140 128 170.5 128 118 Φ4.5
A4055 180 250 169.4 164 235 Φ6 A4055-V1 140 260 155 122 248 Φ6
A4075 180 250 169.4 164 235 Φ6 A4075-V1 140 260 155 122 248 Φ6.
■ Single-phase 200-V class
*2
AE002 80 155 97.4 67 143 Φ5 AB002-V1 68 128 109 56 118 Φ4.5
AE004 80 155 111.4 67 143 Φ5 AB004-V1 68 128 122.5 56 118 Φ4.5
AE007 110 189 132.4 98 176 Φ5 AB007-V1 108 128 170.5 96 118 Φ4.5
