11
Power Supply Units The Power Supply Unit supplies power to the CPU Rack. The Power Supply
Units listed in the following table are available. Refer to 2-2-4 Power Supply
Units for further details.
Model Supply voltage Remarks
C200HW-PA204
100 to 120 VAC,
---
C200HW-PA204S
200 to 240 VAC
Provides 24-VDC output
terminals.
C200HW-PA204R/PA209R
(See note.)
Equipped with RUN output
contacts.
C200HW-PD024 24 VDC ---
Note The C200HW-PA204R/PA209R cannot be used with all combinations of CPU
Units and Backplanes. Refer to page 23, Restrictions for the C200HW-PA204R/
PA209R, for details.
CPU Units The CPU Units listed in the following tables are available. Refer to 2-2-1 CPU
Units for further details on the CPU Units.
Model User
program
memory
Data
memory
Extended
data memory
(EM)
Instruction
processing
time (basic
instructions)
Max. real I/O
points
supported
Max. No. of
Expansion
I/O Racks
C200HE-CPU11-E/ZE 3.2K words 4K words --- 0.3 µs min. 640 points 2 Racks
C200HE-CPU32-E/ZE 7.2K words 6K words --- 0.3 µs min. 880 points 2 Racks
C200HE-CPU42-E/ZE 7.2K words 6K words --- 0.3 µs min. 880 points 2 Racks
C200HG-CPU33-E/ZE 15.2K words 6K words 6K words 0.15 µs min. 880 points 2 Racks
C200HG-CPU43-E/ZE 15.2K words 6K words 6K words 0.15 µs min. 880 points 2 Racks
C200HG-CPU53-E/ZE 15.2K words 6K words 6K words 0.15 µs min. 1,184 points 3 Racks
C200HG-CPU63-E/ZE 15.2K words 6K words 6K words 0.15 µs min. 1,184 points 3 Racks
C200HX-CPU34-E/ZE 31.2K words 6K words 6K words x 3
(18K words)
0.1 µs min. 880 points 2 Racks
C200HX-CPU44-E/ZE 31.2K words 6K words 6K words x 3
(18K words)
0.1 µs min. 880 points 2 Racks
C200HX-CPU54-E/ZE 31.2K words 6K words 6K words x 3
(18K words)
0.1 µs min. 1,184 points 3 Racks
C200HX-CPU64-E/ZE 31.2K words 6K words 6K words x 3
(18K words)
0.1 µs min. 1,184 points 3 Racks
C200HX-CPU65-ZE 63.2K words 6K words 6K words x 8
(48K words)
0.1 µs min. 1,184 points 3 Racks
C200HX-CPU85-ZE 63.2K words 6K words 6K words x 16
(96K words)
0.1 µs min. 1,184 points 3 Racks
Basic Configuration Section 2-1
