12
Model
Max. No. of Group-2
High-density I/O Units
Max. No. of
Special I/O
RS-232C Clock
(RTC)
Communications
Board
64-point Units
(see note 1)
Units
(see note 2)
C200HE-CPU11-E/ZE Not supported Not supported 10 Units No No No
C200HE-CPU32-E/ZE 10 Units 5 Units 10 Units No Yes Yes
C200HE-CPU42-E/ZE 10 Units 5 Units 10 Units Yes Yes Yes
C200HG-CPU33-E/ZE 10 Units 5 Units 10 Units No Yes Yes
C200HG-CPU43-E/ZE 10 Units 5 Units 10 Units Yes Yes Yes
C200HG-CPU53-E/ZE 16 Units 8 Units 16 Units No Yes Yes
C200HG-CPU63-E/ZE 16 Units 8 Units 16 Units Yes Yes Yes
C200HX-CPU34-E/ZE 10 Units 5 Units 10 Units No Yes Yes
C200HX-CPU44-E/ZE 10 Units 5 Units 10 Units Yes Yes Yes
C200HX-CPU54-E/ZE 16 Units 8 Units 16 Units No Yes Yes
C200HX-CPU64-E/ZE 16 Units 8 Units 16 Units Yes Yes Yes
C200HX-CPU65-ZE 16 Units 8 Units 16 Units Yes Yes Yes
C200HX-CPU85-ZE 16 Units 8 Units 16 Units Yes Yes Yes
Note 1. Each 64 I/O Unit is treated as two Units.
2. Special I/O Units like the C200H-NC211 that are allocated the words for two
Units are treated as two Units.
3. Unit number settings for Group-2 Units for the following CPU Units must be
between 0 and 9:
C200HE-CPU32/42-E/ZE
C200HG-CPU33/43-E/ZE
C200HX-CPU34/44-E/ZE
CPU Backplane The CPU Backplane is required to mount the CPU Unit and other Units compos-
ing the CPU Rack. The following CPU Backplanes are available depending on
the number of slot required for Units. Refer to 2-2-5 Backplanes for further
details.
Model Number of slots
C200HW-BC031 3
C200HW-BC051 5
C200HW-BC081-V1 8
C200HW-BC101-V1 10
Note When using the C200HW-PA209R Power Supply Unit with an 8-slot or 10-slot
CPU Backplane or Expansion I/O Backplane, be sure to use the C200HW-
BC081-V1 or C200HW-BC101-V1.
Other Units The other Units that can be mounted to the CPU Rack include the Standard I/O
Units, High-density I/O Units, and Special I/O Units.
Basic Configuration Section 2-1
