Omron C200HE-CPU42 Replacement Guide

25
< Transistor Output Units >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-OD217
CJ1W-OD212
Transistor Output Unit with
terminal block for 12 outputs.
Replace this unit with a
Transistor Output Unit with 16
outputs.
1) Terminal block
2) Output points (12 points → 16 points)
3) Output circuit specifications
Output voltage range (5 to 24 VDC → 24 VDC)
ON response time (1.5 ms → 0.5 ms)
OFF response time (0.5 ms → 1.0 ms)
4) Internal current consumption
(5 VDC: 10 mA → 100 mA,
26 VDC: 75 mA → 0 mA)
5) External power supply
(Not required → 24 VDC: 40 mA)
5 to 24 VDC, 0.3 A, Sourcing,
Terminal block, 12 outputs
24 VDC, 0.5 A, Sourcing,
Terminal block, Load short
circuit protection, 16 outputs
C200H-OD212
CJ1W-OD211
Transistor Output Unit with
terminal block for 16 outputs.
1) Terminal block
2) Output circuit specifications
Residual voltage (1.4 V → 1.5 V)
ON response time (0.2 ms → 0.1 ms)
OFF response time (0.3 ms → 0.8 ms)
4) Internal current consumption
(5 VDC: 180 mA → 100 mA,)
24 VDC, 0.3 A, Sinking,
Terminal block, 16 outputs
12 to 24 VDC, 0.5 A, Sinking,
Terminal block, 16 outputs
C200H-OD21A
CJ1W-OD212
Transistor Output Unit with
terminal block for 16 outputs.
1) Terminal block
2) Output circuit specifications
Output capacity
(1 A/point, 4 A/Unit → 0.5 A/point, 5 A/Unit)
Residual voltage (0.8 V → 1.5 V)
ON response time (0.1 ms → 0.5 ms)
OFF response time (0.3 ms → 1.0 ms)
4) Internal current consumption
(5 VDC: 160 mA → 100 mA)
5) Alarm output (Supported → Not supported)
24 VDC, 1.0 A, Sourcing,
Terminal block, Load short
circuit protection, 16 outputs
24 VDC, 0.5 A, Sourcing,
Terminal block, Load short
circuit protection, 16 outputs
C200H-OD218
CJ1W-OD231
Transistor Output Unit with
connector for 32 outputs.
1) No. of circuits (32 points/common x 1 circuit
→ 16 points/common x 2 circuits)
2) Output circuit specifications
Output voltage range
(5 to 24 VDC → 12 to 24 VDC)
Residual voltage (0.8 V → 1.5 V)
OFF response time (0.4 ms → 0.8 ms)
3) Internal current consumption
(5 VDC: 180 mA → 140 mA)
4.5 to 26.3 VDC, 0.1A, Sinking,
Connector, 32 outputs
(Group-2)
12 to 24 VDC, 0.5A, Sinking,
Connector, 32 outputs
C200H-OD215
CJ1W-OD231
Transistor Output Unit with
connector for 32 outputs.
*The CJ-series Unit does not
support dynamic outputs.
Change the wiring for static
outputs.
1) Connector
Use the XW2Z-S011 Conversion Cable to
reuse the connecting cable.
2) Output method
(Dynamic or static mode → Static mode only)
Based on specifications in static output mode
3) No. of circuits (8 points/common x 4 circuits
→ 16 points/common x 2 circuits)
4) Output circuit specifications
Output voltage range
(5 to 24 VDC → 12 to 24 VDC)
Residual voltage (0.7 V → 1.5 V)
ON response time (0.2 ms → 0.1 ms)
OFF response time (0.6 ms → 0.8 ms)
5) Internal current consumption
(5 VDC: 220 mA → 140 mA)
4.5 to 26.3 VDC, 0.1 A, Sinking,
Connector, 32 outputs
(Special I/O)
12 to 24 VDC, 0.5A, Sinking,
Connector, 32 outputs
C200H-OD21B
CJ1W-OD232
Transistor Output Unit with
connector for 32 outputs.
1) No. of circuits (32 points/common x 1 circuit
→ 16 points/common x 2 circuits)
2) Output circuit specifications
Output capacity (0.5 A/point, 5 A/Unit
→ 0.5 A/point, 2.5 A/common, 4 A/Unit)
Residual voltage (0.8 V → 1.5 V)
ON response time (0.1 ms → 0.5 ms)
OFF response time (0.3 ms → 1 ms)
3) Internal current consumption
(5 VDC: 180 mA → 150 mA)
24 VDC, 0.5 A, Sourcing,
Connector, Load short circuit
protection, 32 outputs (Group-2)
24 VDC, 0.5 A, Sourcing,
Connector, Load short circuit
protection, 32 outputs
C200H-OD219
CJ1W-OD261
Transistor Output Unit with
connector for 64 outputs..
1) No. of circuits (32 points/common x 2 circuits
→ 16 points/common x 4 circuits)
2) Output circuit specifications
Output voltage range
(5 to 24 VDC -> 12 to 24 VDC)
Residual voltage (0.8 V → 1.5 V)
ON response time (0.1 ms → 0.5 ms)
OFF response time (0.4 ms → 1.0 ms)
3) Internal current consumption
(5 VDC: 270 mA → 170 mA)
4.5 to 26.3 VDC, 0.1 A, Sinking,
Connector, 64 outputs
(Group-2)
12 to 24 VDC, 0.3 A, Sinking,
Connector, 64 outputs
