Omron C200HE-CPU42 Replacement Guide

27
♦
Input/Output Units
(1) The CJ Series has following I/O Units: CJ1W-MD23□, CJ1W-MD26□, and CJ1W-MD563.
(2) Refer to the related manuals for details. Although CJ-series Units have basic functions of C200H-series Units,
some specifications may differ.
< DC Input/Transistor Output Units >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-MD115
CJ1W-MD231
I/O Unit with connector for 16
inputs and 16 outputs.
*The CJ-series Unit does not
support dynamic outputs.
Change the wiring for static
outputs.
1) Connector
2) Output method
(Dynamic or static mode → Static mode only)
3) Internal current consumption
(5 VDC: 180 mA → 130 mA)
Based on specifications in static output mode
< Output circuit >
4) No. of circuits (8 points/common x 2 circuits
→ 16 points/common x 1 circuit)
5）Output circuit specifications
Output voltage range
(5 to 24 VDC → 12 to 24 VDC)
Residual voltage (0.7 V → 1.5 V)
ON response time (0.2 ms → 0.1 ms)
OFF response time (0.6 ms → 0.8 ms)
< Input circuit >
6) No. of circuits (8 points/common x 2 circuits
→ 16 points/common x 1 circuit)
7) Input circuit specifications
Input voltage (12 VDC → 24 VDC)
Input impedance (2.7 kΩ → 3.3 kΩ)
ON voltage (8 VDC → 14.4 VDC)
OFF voltage (3 VDC → 5 VDC)
12 VDC/16 inputs (4.1 mA),
12 VDC/16 outputs (0.1A,
Sinking), Connector
(Special I/O)
24 VDC/16 inputs (7 mA),
12 to 24VDC/16 outputs
(0.5 A, Sinking), Connector
C200H-MD215
CJ1W-MD231
I/O Unit with connector for 16
inputs and 16 outputs.
*The CJ-series Unit does not
support dynamic outputs.
Change the wiring for static
outputs.
1) Connector
2) Output method
(Dynamic or static mode → Static mode only)
3) Internal current consumption
(5 VDC: 180 mA → 130 mA)
Based on specifications in static output mode
< Output circuit >
4) No. of circuits (8 points/common x 2 circuits
→ 16 points/common x 1 circuit)
5）Output circuit specifications
Output voltage range
(5 to 24 VDC → 12 to 24 VDC)
Residual voltage (0.7 V → 1.5 V)
ON response time (0.2 ms → 0.1 ms)
OFF response time (0.6 ms → 0.8 ms)
< Input circuit >
6) No. of circuits (8 points/common x 2 circuits
→ 16 points/common x 1 circuit)
7) Input circuit specification
Input impedance (5.6 kΩ → 3.3 kΩ)
24 VDC/16 inputs (4.1 mA),
5 to 24 VDC/16 outputs (0.1 A,
Sinking), Connector
(Special I/O)
24 VDC/16 inputs (7 mA),
12 to 24VDC/16 outputs
(0.5 A, Sinking), Connector
