Appendix DDimensions and Mounting Methods
217
Analog Timer Unit
The dimensions shown below are for the Analog Timer Unit classified as Special I/O Units.
130
35
101
Backplane
118
Group-2 High-density I/O Units
The dimensions shown below are for the Group-2 High-density I/O Units.
130
35
101
118
C and D Types
Backplane
Backplane
Approx. 143
High-density I/O Units (Special I/O Units)
The dimensions shown below are for the High-density I/O Units classified as Special I/O Units.
130
35 101
Backplane
