Omron C200HX Series Replacement Guide

8
< I/O Units and CPU Bus Units>
Unit name
C200H-series Unit
CJ-series Unit
Description
Basic I/O Unit
C200H-I□□□
C200H-O□□□
C200H-M□□□
CJ1W-I□□□
CJ1W-O□□□
CJ1W-M□□□
Refer to Appendix E. Table of Input/Output
Units for CJ-series Basic I/O Units
corresponding to C200H-series Basic I/O
Units.
Special I/O Unit
C200H-□□□□
CJ1W-□□□□
Select a required model to replace the
C200H-series Unit. Refer to the manuals of
Special I/O Units for specifications.
When there is no CJ-series Special I/O Unit
which has the same functions and
specifications as the C200H-series Unit, we
recommend you to use another CJ-series
Special I/O Unit instead.
Communication Unit
[SYSMAC LINK]
Coaxial: C200HW-SLK23/24
Optical: C200HW-SLK13/14
[SYSMAC LINK]
None
[Controller Link]
Wired: CJ1W-CLK23
Optical: None
SYSMAC LINK cannot be used with the
CJ2-series CPU Unit.
We recommend you to use Controller Link
instead.
Refer to the Controller Link Units Operation
Manual (Cat. No. W309) for details.
[SYSMAC NET]
C200HS-SNT32
[SYSMAC NET]
None
[Controller Link]
Wired: CJ1W-CLK23.
Optical: None
SYSMAC NET cannot be used with the
CJ2-series CPU Unit.
We recommend you to use Controller Link
instead.
Refer to the Controller Link Units Operation
Manual (Cat. No. W309) for details.
[Controller Link]
Wired: C200HW-CLK21
[Controller Link]
Wired: CS1W-CLK23
To replace with the CJ-series Unit, change
the related areas including the Status Area.
Refer to the Controller Link Units Operation
Manual (Cat. No. W309) for details.
[Host Link]
[Serial Communications]
C200H-series Host Link Units cannot be
used with the CJ2-series CPU Unit.
Refer to the SYSMAC CS/CJ Series Serial
Communications Boards/Units OPERATION
MANUAL (Cat. No. W336) for details.
C200H-LK101-PV1
None
CJ1W-SCU21-V1
(+ optical link module)
The CJ Series does not have an Optical-type
Serial Communications Board/Unit. Use the
wired type instead or use an external optical
link module.
C200H-LK201-V1
CJ1W-SCU21-V1
CJ1W-SCU41-V1
Host Link port built in the
CPU Unit
*For CJ2M-CPU3□,
CP1W-CIF01 is required.
Use one of the left CJ-series Units/Boards..
*CJ2M-CPU3□ does not have a built-in Host
Link port. Purchase the CP1W-CIF01
RS-232C Option Board.
C200H-LK202-V1
CJ1W-SCU31-V1
CJ1W-SCU41-V1
Use one of the left CJ-series Units/Boards.
[PC Link]
C200H-LK401
[PC Link]
None
[Controller Link]
Wired: CJ1W-CLK23.
Optical: None
PC Link cannot be used with the CJ2-series
CPU Unit.
We recommend you to use Controller Link
instead.
Refer to the Controller Link Units Operation
Manual (Cat. No. W309) for details.
