Omron C200HX Series Replacement Guide

26
< TTL Output Unit >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-OD501
No replacement model
TTL Output Unit with connector for 32 outputs. The CJ Series does not have the
same type of Unit.
Use C200H-OD501 with CJ2 or use the CJ1W-OD231 Transistor Output Unit or
CJ1W-MD563 TTL I/O Unit instead.
5 VDC, 35 mA, Connector,
32 outputs (Special I/O)
< Triac Output Units >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-OA223
CJ1W-OA201
Triac Output Unit with
terminal block for 8 outputs.
1) Terminal block
2) Output circuit specifications
Output capacity (1.2 A/point, 4 A/unit
→ 0.6 A/point, 2.4 A/Unit)
Max. inrush current
(15 A/100 ms, 30 A/10 ms → 15 A/10 ms)
Residual voltage (50 to 1200 mA: 1.5 VAC,
10 to 50 mA: 5 VAC → 1.6 VAC).
3) Internal current consumption
(5 VDC: 180 mA → 220 mA)
250 VAC, 1.2 A, Terminal block,
8 outputs
250 VAC, 0.6 A, Terminal block,
8 outputs
C200H-OA221
CJ1W-OA201
Triac Output Unit with
terminal block for 8 outputs.
1) Terminal block
2) Output circuit specifications
Output capacity (1 A/point, 4 A/unit
→ 0.6 A/point, 2.4 A/Unit)
Max. inrush current
(No regulation → 15 A/10 ms)
Residual voltage (1.2 VAC → 1.6 VAC)
OFF response time (1/2 of load frequency or
less → 1/2 of load frequency + 1 ms or less)
3) Internal current consumption
(5 VDC: 140 mA → 220 mA)
250 VAC, 1.2 A, Terminal block,
8 outputs
250 VAC, 0.6 A, Terminal block,
8 outputs
C200H-OA224
CJ1W-OA201
Triac Output Unit with
terminal block for 12 outputs.
Replace this unit with two
Triac Output Units with 8
outputs.
1) Terminal block
2) Output points (12 points → 8 points x 2)
3) No. of circuits (12 points/common x 1 circuit →
8 points/common x 1 circuit x 2)
4) Output circuit specifications
Output capacity (250 VAC 0.5 A/point, 2 A/unit
→ 0.6 A/point, 2.4 A/Unit x 2)
Max. inrush current
(10 A/100 ms, 20 A/10 ms → 15 A/10 ms)
Residual voltage (50 to 500 mA: 1.5 VAC,
10 to 50 mA: 5 VAC → 1.6 VAC).
5) Internal current consumption
(5 VDC: 270 mA → 220 mA x 2)
250 VAC, 0.5 A, Terminal block,
12 outputs
250 VAC, 0.6 A, Terminal block,
8 outputs
C200H-OA222V
CJ1W-OA201
Triac Output Unit with
terminal block for 12 outputs.
Replace this unit with two
Triac Output Units with 8
outputs.
1) Terminal block
2) Output points (12 points → 8 points x 2)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 1 circuit x 2)
4) Output circuit specifications
Max. inrush current
(No regulation → 15 A/10 ms)
Residual voltage (1.2 VAC → 1.6 VAC)
ON response time
(1/2 of load frequency or less → 1 ms or less)
OFF response time (1/2 of load frequency or
less → 1/2 of load frequency + 1 ms or less).
5) Internal current consumption
(5 VDC: 200 mA → 220 mA x 2)
250 VAC, 0.3 A, Terminal block,
12 outputs (CE marked)
250 VAC, 0.6 A, Terminal block,
8 outputs
