9. Connect the GREY (1 BLACK BAND) wire to output 100.04 – this is the ‘ERROR
COUNTER RESET’ signal which resets the drive’s internal following error counter in
the event of a fault caused by this.
10. Connect the ORANGE (1 BLACK BAND) wire to output 100.06 – this is the ‘RUN’
command signal to the drive.
11. Connect the GREY (1 RED BAND) wire to output 100.07 – this is the ‘RESET’
signal to the drive, to be used after an error.
