30
Unit Components Section 3-3
CS1W-ETN01 and CS1W-ETN11
Each communications device connected to the Ethernet network is allocated
a unique Ethernet address. For the Ethernet Unit, this Ethernet address is
shown on the right side of the Unit as a 12-digit hexadecimal number.
Note The Ethernet address can also be checked using the FINS command, CON-
TROLLER DATA READ. (Refer to 11-3-2 CONTROLLER DATA READ.)
Local IP Address Switches
Used to set the Ethernet Unit's IP address
in eight digits hexadecimal.
Back
Ethernet address (12 digits)
