Ordering Guide
Engineering time can be reduced significantly
by combining the LCB/LCU with an NS-series PT.
Note: The computer can be connected to the peripheral port or
RS-232C port of a SYSMAC PLC CPU Unit or the RS-232C port of a Serial Communications Board/Unit.
Note: CX-One Lite includes the CX-Integrator, CX-Programmer, CX-Simulator, Switch Box Utility, CX-Designer, and Ladder Monitor software.
CX-One is compatible with Windows 2000 if service pack 3 or later has been installed. If the service pack has not been updated to SP 3 or later, download the latest
service pack from Microsoft’s web site: http://www.microsoft.com/windows2000/downloads/servicepacks/default.asp.
Create Special Screens for Loop Control. (NS-series Face Plate Auto-Builder)
• Programs can be created just by pasting and connecting function
blocks provided for process control (such as the PID calculation
block). Step ladder/sequence table language is also provided
for sequence control programming.
• The plentiful debugging functions support system startup and
provide easy engineering. For example, the tuning window can
be opened for operations such as monitoring/changing trend
data or parameters and saving trend data.
The Support Software for a Loop Control Board or
Unit (CX-Process) can be started directly from
a CX-Programmer PLC I/O table.
Loop Control Board/Unit Support Software Startup with inherited Unit Information
For more information and to get your free 30-day trial version of Cx-One then please go to
CX-One FA Support Tool Package
• This software can automatically build screen data for
NS-series Touch Panels from the tag information
(tag names, tag comments, scaling, I/O allocation, etc.)
created in the CX-Process Tool’s Control and
Tuning Windows.
• Eliminates time-consuming steps such as allocating
communications addresses and ladder programming
for the NS-series PTs.
• The created data can be edited and processed freely
in the CX-Designer Screen Development Software.
Function block diagram
Sequence table
Tuning WindowNote: Project data can be called up from the File Menu.
CX-Process NS-Designer
Specifications Model number Overseas Standards
FA Support Tool Package
For Windows 98 SE, Me, NT 4.0 (Service Pack 6a),
2000 (Service Pack 3 or higher), or XP.
CX-One, One license CXONE-AL01C-E –
CX-One, Three licenses CXONE-AL03C-E –
CX-One, Ten licenses CXONE-AL10C-E
–
• Site licenses are available for users that will operate CX-One on multiple computers. Contact your OMRON representative for details.
• For users of separate Support Software applications contained in the CX-One FA Support Tool Package, there are also versions available to transfer and upgrade
to CX-One. Contact your OMRON representative for details.
