E5AX-LA/-MA
E5AX-LA/-MA
13
Dimensions
Note: All units are in millimeters unless otherwise indicated.
12
89
11
2 to 11
Mounting
screw
Communications connector
(RS-232C and BCD connector is shown.)
Communications board
(RS-422 and 485 terminals are shown.)
Communications board
(4 to 20 mA transmission output is shown.)
4 to 20 mA
transmission output
RS-422 RS-485
RDB
RDA
SG
SDA
SDB
Panel Cutout Side-by-side Mounting
of N Controllers
92
+0.8
0
92
+0.8
0
92
+0.8
0
120 min.
L
L = (96N – 3.5)
+1
0
_96
SG
