Omron G7L User Manual

G7L
G7L
10
G7L -2A-TUBJ
with Test Button
Mounting HolesTerminal Arrangement/
Internal Connections
(Top View)
Two, 4.5-dia. hole or
M4 tapped holes
Screw Terminals with E-bracket
Note:
E-brackets are sold separately.
G7L-1A-B
G7L-2A-B
G7L-1A-BJ
with Test Button
G7L-2A-BJ
with Test Button
Terminal Arrangement/
Internal Connections
(Top View)
Mounting Holes
Two, M3.5 screws
for coil
Two, M3.5 screws
for coil
Two, M3.5 screws
for coil
Two, M3.5 screws
for coil
Two, M4 screws
for contact
Four, M4 screws
for contact
Two, M4 screws
for contact
Four, M4 screws
for contact
Two, 4.5-dia. hole
or M4 tapped holes
