G7L
G7L
12
G7L -2A-BUB
G7L -1A-BUBJ
with Test Button
G7L -2A-BUBJ
with Test Button
Mounting Holes
Terminal Arrangement/
Internal Connections
(Top View)
Terminal Arrangement/
Internal Connections
(Top View)
Terminal Arrangement/
Internal Connections
(Top View)
Two, M3.5 screws
for coil
Four, M4 screws
for contact
Two, M3.5 screws
for coil
Two, M3.5 screws
for coil
Two, M4 screws
for contact
Four, M4 screws
for contact
Two, 4.5-dia. hole
or M4 tapped holes
PCB Terminals with PCB Mounting
G7L-1A-P
G7L-2A-P
Terminal Arrangement/
Internal Connections
(Top View)
Terminal Arrangement/
Internal Connections
(Top View)
Mounting Holes
(Bottom View)
Mounting Holes
(Bottom View)
