Omron H3BH User Manual

H5F
H5F
239
Track Mounting
76.1 (See note 1)
84.8 (See note 2)
63.1 (See note 1)
71.8 (See note 2)
Note: 1. With mounting tracks PFP-100N or PFP-50N.
2. With mounting track PFP-100N2.
Mounting Track (Meets DIN EN50022)
PFP-100N/PFP-50N
PFP-100N2
Note: This dimension applied to PFP-50N.
(See note)
Twelve, 25
'
4.5 elliptic holes
Installation
Connections
Flush Mounting
H5F-B
H5F-FB
Surface/Track Mounting
H5F-KB
