Omron H3CR Series User Manual

H3CR-A
H3CR-A
13
Operating
mode
Timing chart
D:
Signal
OFF-delay
Basic operation
Power
Output
t
Output relay (NC)
Power indicator
Power
Start
Reset
Output relay (NO)
(Output indicator)
Note: Start input is valid and
re-triggerable while the
Timer is in operation.
Start
(see note)
E:
Interval
Power
Output
t
Basic operation
Power
Start
Reset
Output relay (NC)
Power indicator
Output relay (NO)
(Output indicator)
Note: Start input is valid and
re-triggerable while
the Timer is in opera-
tion.
Start
(see note)
G:
Signal
ON/OFF-
delay
Basic operation
Power
Start
Reset
Output relay (NC)
Power indicator
Power
Output
t
t
Output relay (NO)
(Output indicator)
Note: Start input is valid and re-trigger-
able while the Timer is in operation.
t
t
Start
(see note)
J:
One-shot
output
Basic operation
Power
Start
Reset
Output relay (NC)
Power indicator
1±0.6 s
(Fixed)
1±0.6 s
(Fixed)
Output
Power
Output relay (NO)
(Output indicator)
1±0.6 s
(Fixed)
Note: Start input is valid and re-
triggerable while the Timer
is in operation.
Start
(see note)
t
Gate Signal Input
Power
Start
Gate
Reset
Output
relay
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
Note: 1. This timing chart indicates the gate input in op-
erating mode A (ON-delay operation).
2. The set time is the sum of t
1
and t
2
.
3. H3CR-AP model incorporates start input only.
t
1
t
2
Downloaded from Elcodis.com electronic components distributor

Omron H3CR Series Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Number of Pins	8 or 11 (depending on model)
Type	Solid State Timer
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Contact Rating	5A at 250V AC
Contact Configuration	SPDT
Storage Temperature	-25 to 65°C
Operating Modes	On-delay, One-shot, Interval, Flicker, Signal On/Off
