H3CR-G
H3CR-G
35
Dimensions
Note: All units are in millimeters unless otherwise indicated.
15
6
78.0
63.7
39 dia. 44.8 x 44.8
0.7
48
48
8 pins
Dimensions with Set Ring
Time setting ring Panel cover
50
16.5
50
42 dia.
P2CF-08
101.3*
99
2.3
*
Y92F-30
P3G-08
15
86.4
H3CR-G8jL
P2CF-08-E
H3CR-
G8jL
Dimensions with Front Connecting Socket
P2CF-08-j
Dimensions with Back Connecting Socket
P3G-08
*
These dimensions vary with the kind of DIN track (reference value).
(When
Y92A-48G
mounted)
92.9
Installation
Terminal Arrangement
H3CR-G8L H3CR-G8EL
( ~ )( ~ )
Instantaneous contact
Star
operation
contact
Delta
operation
contact
( ~ )( ~ )
Star
operation
contact
Delta
operation
contact
Note: Leave terminals 1, 3, and 4 open.
Do not use them as relay terminals.
Note: Leave terminal 4 open. Do not use
them as relay terminals.
