Omron H3CR Series - Accessories and Specifications (H3 CR-H); Optional Accessories; General and Time Range Specifications

H3CR-H
H3CR-H
37
Accessories (Order Separately)
Name/specifications Models
Flush Mounting Adapter
Y92F-30
gp
Y92F-70
Y92F-71
Mounting Track
50 cm (l) x 7.3 mm (t)
PFP-50N
1 m (l) x 7.3 mm (t)
PFP-100N
1 m (l) x 16 mm (t)
PFP-100N2
End Plate PFP-M
Spacer PFP-S
Protective Cover Y92A-48B
Track Mounting/
FtC tiSkt
8-pin P2CF-08
g
Front Connecting Socket
8-pin, finger safe type P2CF-08-E
11-pin P2CF-11
11-pin, finger safe type P2CF-11-E
Back Connecting Socket
8-pin P3G-08
g
8-pin, finger safe type P3G-08 with Y92A-48G (see note 1)
11-pin P3GA-11
11-pin, finger safe type P3GA-11 with Y92A-48G (see note 1)
Hold-down Clip (see note 2) For PL08 and PL11 Sockets Y92H-1
For PF085A Socket Y92H-2
Note: 1. Y92A-48G is a finger safe terminal cover which is attached to the P3G-08 or P3GA-11 Socket.
2. Hold-down Clips are sold in sets of two.
Specifications
General
Item H3CR-H8L H3CR-H8RL H3CR-HRL
Operating/Reset method Instantaneous
operation/Time-limit reset
Instantaneous operation/Time-limit reset/Forced reset
Pin type 8-pin 11-pin
Input type --- No-voltage
Output type Relay output (DPDT) Relay output (SPDT) Relay output (DPDT)
Mounting method DIN track mounting, surface mounting, and flush mounting
Approved standards UL508, CSA C22.2 No.14, NK, Lloyds
Conforms to EN61812-1 and IEC60664-1 (VDE0110) 4kV/2.
Output category according to EN60947-5-1.
Time Ranges
Time unit S-series M-series
s (sec) min
Setting 0.6 0.05 to 0.6
1.2 0.1 to 1.2
6 0.5 to 6
12 1 to 12
Min. power ON time 0.1 s min. 2 s min.
Note: If the above minimum power ON time is not secured, the H3CR may not operate. Be sure to secure the above minimum power ON time.
