Omron H3CR Series - Page 41

H3CR-H
H3CR-H
43
Installation
Terminal Arrangement
Note: DC models, including 24 VAC/DC models, have polarity.
8-pin Models
Without Reset Input (H3CR-H8L)
With Reset Input (H3CR-H8RL)
11-pin Model
With Reset Input (H3CR-HRL)
Power supply
(+)
(~)
(–)
(~)
Power supply
(–)(~)
(+)(~)
Power supply
(+)
(~)
(–)
(~)
Reset
input
Reset input
Note: Leave terminal 3 open. Do not use
them as relay terminals.
Note: Leave terminal 6 open. Do not use
them as relay terminals.
