H2E
H2E
272
Mounting Dimensions
Surface Mounting
H2E, H2E-2
Mounting Holes
Flush Mounting
H2E-Y, H2E-Y2
Mounting Holes
Three, M4 taps
Panel
Exclusive-use
mounting bracket
(see note)
Panel
Mounting bracket
1R max.
102
!
0.4
Note: The mounting panel thickness
should be 1 to 3.2 mm.
74
!
0.488
8
10
87
!
0.5
120
117
!
0.5
90
106
Installation
Connections
H2E, H2E-Y H2E-2, H2E-Y2
100/110, 200/220 VAC
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. L10-E1-8
