Engineering Data
H3Y-2
Switching operations (x 10 )
3
Load current (A)
H3Y-2
H3Y-4
Switching operations (x 10 )
3
Load current (A)
Switching operations (x 10 )
3
Load current (A)
H3Y-4
Switching operations (x 10 )
3
Load current (A)
250 VAC, cosφ = 1
24 VDC, cosφ = 1
250 VAC, cosφ = 0.4
24 VDC, L/R = 7 ms
250 VAC, cosφ = 1
24 VDC, cosφ = 1
250 VAC, cosφ = 0.4
24 VDC, L/R = 7 ms
Reference: A maximum current of 0.6 A can be
switched at 125 VDC (cosφ = 1).
Maximum current of 0.2 A can be
switched if L/R is 7 ms. In both
cases, a life of 100,000 operations
can be expected.
The minimum applicable load is
1 mA at 5 VDC (P reference value).
Reference: A maximum current of 0.5 A can be
switched at 125 VDC (cosφ = 1).
Maximum current of 0.2 A can be
switched if L/R is 7 ms. In both
cases, a life of 100,000 operations
can be expected.
The minimum applicable load is
1 mA at 1 VDC (P reference value).
Operation
Timing Chart
H3Y-2 H3Y-4
Time limit contact
NC (9-1, 12-4)
Time limit contact NC
(9-1, 10-2, 1 1-3, 12-4)
