Omron H5CX Datasheet

The H5CX Timer
Actual size
H5CX
- Timer
- Twin Timer
Features at a glance!
Display:
Benefits to you:
• Back-lit LCD; two colours
- Very high visibility
• Height present value 11.5 mm
- Programmable present value colour
• Height set-value 6 mm green
- Set-value can be changed very easily by rocker key per digit
• Status indicators
- All information on the screen
• Time running indicator
- Feedback of operation
Multiple timing ranges:
• Four ‘seconds’ time ranges
- Precise time control up to 0.001 s
• Two ‘minutes’ time ranges
- Direct read-out in minutes with an accuracy of 0.1 min
• Two ‘hours’ time ranges
- Long precise time control
•‘Min’ and ‘Seconds’
- Easy real read-out measuring time
•‘Hours’ and ‘Minutes’
- Up to 99 h and 99 m read out
Functions:
• All standard timer functions
- Always right model available
• Includes real twin timer operation
- To cover 99% of all your applications
• Functions with memory feature
- Completes timing process when process resumes
Connection / mounting:
• Screw-terminal wiring
- Conforms to VDE0106/P100 norm (finger safe)
• Plug-in 8- or 11-pins
- Easy maintenance
• Front-panel
- Standard hole size 45 x 45 mm
Output control:
• Relay 5 A/250 VAC change-over
- Always the right output
• Transistor 100 mA at 30 VDC
- Suitable for all industrial needs
}
H5CX-A 100 to 240 VAC
H5CX-AD 12 to 24 VDC / 24 VDAC
Full datasheet available from our Website: www.eu.omron.com
The H5CX series offers multiple timing ranges for precise
timing control, as well as real twin-timing and memory
function. These and other added-value features ensure that
the H5CX covers almost every possible user requirement
in timers.
With real twin-timer function
The H5CX is also a real twin-timer with independent On/Off
time setting. With the twin-timer function you can vary the
Off-time and On-time periods to suit a variety of applications.
You can also set the On-time and Off-time as a percentage of
your set time-base. This extra functionality makes the H5CX
the most complete timer on the market.
Memory function
A few functions are equipped with a built-in memory circuit
that ‘freezes’ the timing condition in the event of a process or
power failure and completes the process when normal
production resumes or when power is restored.
Best choice:
• All timing functions
• Screw terminals
• Relay output

Omron H5CX Specifications

General

Brand	Omron
Model	H5CX
Category	Timer
Language	English
