General-purpose Relay LY A-41
Electromechanical
Relays
Upper-mounting Relays
2
0.5
5
3
6.4
3.5
38
38±0.1
LY1F
LY2F
35.5 max.
22.5 max.
Mounting Holes
Note: 1. Eight 3-dia. holes should apply to
the LY2F model.
Two, 3.5-dia.
holes (or Two
M3 holes)
44
max.
29
max.
Eight, 2-dia.
holes (see note)
LY3F
0.5
5
3
6.4
3.5
38
38±0.1
2
36 max.
32 max.
44 max.
Two, 3.5-dia. holes
(or two, M3 holes)
28.5
max.
Eleven,
3-dia. holes
LY4F
2
0.5
5
3
6.4
3.5
28
38
28±0.1
38±0.1
35.5 max.
Mounting holes
41.5 max.
Two, 3.5 dia. holes (or
two, M3 holes)
44
max.
28
max.
Fourteen,
3-dia. holes
