A-32 General-purpose Relay LY
■ Accessories (Order Separately)
Sockets
Note: 1. For PTF08-E and PTF14A-E, see “Track Mounted Socket.”
2. PTF@A (-E) Sockets have met UL and CSA standards: UL 508/CSA C22.2.
Mounting Plates for Sockets
Socket-Hold-down Clip Pairings
Specifications
■ Coil Ratings
Single- and Double-pole Relays
Note: See notes on the bottom of next page.
Poles Front-connecting Socket Back-connecting Socket
DIN track/screw terminals Plug-in/solder terminals Wrapping terminals PCB terminals
1 or 2 PTF08A-E, PTF08A PT08 PT08QN PT08-0
3 PTF11A PT11 PT11QN PT11-0
4 PTF14A-E, PTF14A PT14 PT14QN PT14-0
Socket model For 1 Socket For 10 Sockets For 12 Sockets For 18 Sockets
PT08
PT08QN
PYP-1 --- --- PYP-18
PT11
PT11QN
PTP-1-3 --- PTP-12 ---
PT14
PT14QN
PTP-1 PTP-10 --- ---
Relay type Poles Front-connecting Sockets Back-connecting Sockets
Socket model Clip model Socket model Clip model
Standard, bifurcated contacts oper-
ation indicator, built-in diode
1, 2 PTF08A-E, PTF08A PYC-A1 PT08(QN), PT08-0 PYC-P
3 PTF11A PT11(QN), PT11-0
4 PTF14A-E, PTF14A PT14(QN), PT14-0
CR circuit 2 PTF08A-E, PTF08A Y92H-3 PT08(QN), PT08-0 PYC-1
Rated voltage Rated current Coil
resistance
Coil inductance
(reference value)
Must
operate
voltage
Must
release
voltage
Max.
voltage
Power
consum.
(approx.)
50 Hz 60 Hz Arm. OFF Arm. ON % of rated voltage
AC 6 V 214.1 mA 183 mA 12.2 Ω 0.04 H 0.08 H 80% max. 30% min. 110% 1.0 to 1.2 VA
(60 Hz)
12 V 106.5 mA 91 mA 46 Ω 0.17 H 0.33 H
24 V 53.8 mA 46 mA 180 Ω 0.69 H 1.30 H
50 V 25.7 mA 22 mA 788 Ω 3.22 H 5.66 H
100/110 V 11.7/12.9 mA 10/11 mA 3,750 Ω 14.54 H 24.6 H 0.9 to 1 VA
(60 Hz)
110/120 V 9.9/10.8 mA 8.4/9.2 mA 4,430 Ω 19.20 H 32.1 H
200/220 V 6.2/6.8 mA 5.3/5.8 mA 12,950 Ω 54.75 H 94.07 H
220/240 V 4.8/5.3 mA 4.2/4.6 mA 18,790 Ω 83.50 H 136.40 H
DC 6 V 150 mA 40 Ω 0.16 H 0.33 H 10% min. 0.9 W
12 V 75 mA 160 Ω 0.73 H 1.37 H
24 V 36.9 mA 650 Ω 3.20 H 5.72 H
48 V 18.5 mA 2,600 Ω 10.6 H 21.0 H
100/110 V 9.1/10 mA 11,000 Ω 45.6 H 86.2 H
