A-36 General-purpose Relay LY
■ Approved Standards
UL 508 Recognitions (File No. 41643)
CSA 22.2 No. 14 Listings (File No. LR31928)
SEV Listings (File No. D3,31/137)
TÜV (File No. R9251226) (IEC255)
VDE Recognitions (No. 9903UG and 9947UG)
LR Recognitions (No. 563KOB-204523)
No. of poles Coil ratings Contact ratings Operations
1 6 to 240 VAC
6 to 125 VDC
15 A, 30 VDC (Resistive)
15 A, 240 VAC (General use)
TV-5, 120 VAC
1/2 HP, 120 VAC
6 x 10
3
25 x 10
3
2 15 A, 28 VDC (Resistive)
15 A, 120 VAC (Resistive)
12 A, 240 VAC (General use)
1/2 HP, 120 VAC
6 x 10
3
25 x 10
3
3 and 4 10 A, 30 VDC (Resistive)
10 A, 240 VAC (General use)
1/3 HP, 240 VAC
6 x 10
3
No. of poles Coil ratings Contact ratings Operations
1 6 to 240 VAC
6 to 125 VDC
15 A, 30 VDC (Resistive)
15 A, 120 VAC (General use)
1/2 HP, 120 VAC
TV-5, 120 VAC
6 x 10
3
25 x 10
3
2 15 A, 30 VDC (Resistive)
15 A, 120 VAC (Resistive)
1/2 HP, 120 VAC
TV-3, 120 VAC
6 x 10
3
3 and 4 10 A, 30 VDC (Resistive)
10 A, 240 VAC (General use)
No. of poles Coil ratings Contact ratings Operations
1 6 to 240 VAC
6 to 125 VDC
15 A, 24 VDC
15 A, 220 VAC
6 x 10
3
2 to 4 10 A, 24 VDC
10 A, 220 VAC
No. of poles Coil ratings Contact ratings Operations
1 to 4 6 to 125 VDC
6 to 240 VAC
LY1 , LY 1 - F D
15 A, 110 VAC (cosφ=1)
10 A, 110 VAC (cosφ=0.4)
LY2, LY2-FD, LY3, LY3-FD, LY4,
LY 4 - FD
10 A, 110 VAC (cosφ=1)
7.5 A, 110 VAC (cosφ=0.4)
100 x 10
3
No. of poles Coil ratings Contact ratings Operations
1 6, 12, 24, 50, 110, 220 VAC
6, 12, 24, 48, 110 VDC
10 A, 220 VAC (cosφ=1)
7 A, 220 VAC (cosφ=0.4)
10 A, 28 VDC (L/R=0 ms)
7 A, 28 VDC (L/R=7 ms)
200 x 10
3
2 7 A, 220 VAC (cosφ=1)
4 A, 220 VAC (cosφ=0.4)
7 A, 28 VDC (L/R=0 ms)
4 A, 28 VDC (L/R=7 ms)
No. of poles Coil ratings Contact ratings
2, 4 6 to 240 VAC
6 to 110 VDC
7.5 A, 230 VAC (PF0.4)
5 A, 24 VDC (L/R=7 ms)
