General-purpose Relay LY A-39
Electromechanical
Relays
Note: The DC models have polarity.
Note: The DC models have polarity.
0.5
5
3
6.4
LY2(Z)
LY2(Z)-D
LY2(Z)N LY2(Z)N-D2
LY2 LY2 Z
LY2-D LY2Z-D
LY2N LY 2ZN
LY2N-D2 LY2ZN-D2
Eight, 3-dia. holes
36 max.
28 max.
DC Model
AC Model
21.5 max.
Terminal Arrangement/Internal
Connections (Bottom View)
0.5
5
3
6.4
LY3
LY3-D LY3N
LY3Z
LY3N
LY3-D
Eleven, 3-dia. holes
28 max.
31.5 max.
Terminal Arrangement/Internal Connections (Bottom View)
DC Model AC Model
36.5 max.
