Omron Micro A-I-R NE-U22 User Manual

15
Correct Use of the Unit How to Care the Unit after Inhalation
6 After assembling the unit, store it in
a clean place.
5 Wipe off the stain on the Main Unit.
Wipe off the stain on the Main Unit with gauze.
If the Main Unit is heavily stained, lightly moisten gauze
with water and wipe the stain off. Then use new gauze
to wipe the Main Unit dry.
4 Dry the parts thoroughly.
Immediately after washing the parts, wipe off water
with new gauze and dry them thoroughly.
Do not insert your
finger into the
Nebulization Port.
General advice
Never try to wipe off water with tissues
or cloth.
• Dust or lint left on the Mesh may
affect nebulization.
General advice
Do not wipe the Main Unit with volatile
agent such as benzene or thinner.
Keep the Electrodes clean.
Immediately dry the cleaned and
disinfected parts, then store them in a
clean place.
• Miscellaneous bacteria may
propagate and may lead to
infection.
How to remove the Mesh Cover
When washing a Mesh
cap, you can remove
the Mesh Cap Cover
as shown in the Figure.
- Do not insert your
finger into the Mesh
Cap.
Do not insert your
finger into the
Nebulization Port.
- Be sure to install
the Mesh Cap
Cover to the Mesh
Cap after cleaning.
EN-p2-20-(NE-U22)-3 3/25/02 4:48 PM Page 15

Omron Micro A-I-R NE-U22 Specifications

Power

power source	3 VDC (two AA alkaline batteries), 2.4 VDC (two AA nickel-hydrogen batteries)
power consumption	1.5 W

Technical Specifications

ultrasonic frequency	180 kHz
nebulization rate	0.25 ml / minute or more
particle size	5 µm

Capacity and Dimensions

medication bottle capacity	7 ml
external dimensions	38 (W) x 104 (H) x 51 (D) mm
weight	97 g

Battery and Operating Life

battery life with continuous nebulization	4 hours
battery life with daily use	8 days
operating temperature	10 to 40°C
