Omron MY - Page 12

12 General-purpose Relay MY New model
---
Socket Dimensions Terminal arrangement/
Internal connections
(top view)
Mounting holes
PYF14S
36.5 max.
31 max.
85 max.
PYF14A-E
31 max.
29.5 max.
72 max.
Two, 4.2 x 5
mounting
holes
Fourteen, M3 x 8
sems screws
(TOP VIEW)
Two, M3, M4, or 4.5-dia. holes
Note: Track mounting is also
possible. Refer to page
12 for supportin
g
tracks.
PYF14A-N
4
42
3
32
2
22
1
12
8
44
7
34
6
24
5
14
41
12
31
11
21
10
11
9
A1
13
A2
14
A2
14
PYF-14A-N
73
30 max.
67 max.
29.5 max.
4 3 2 1
8 7 6 5
12 11 10 9
14 14
13
42 32 22 12
44
34 24 14
41 31 21 11
A2 A2 A1
26
Two, 4.5 dia. or M4
Note: Track mounting is also
possible. Refer to page
12 for supporting tracks.
