2 General-purpose Relay MY New model
■ Accessories (Order Separately)
Sockets
Socket Hold-down Clip Pairing
Mounting Plates for Sockets
Note: PYP-18 and PYP-36 can be cut into any desired length in accordance with the number of Sockets.
Track and Accessories
Specifications
■ Coil Ratings
Note: 1. The rated current and coil resistance are measured at a coil temperature of 23°C with tolerances of +15%/–20% for rated currents and
±15% for DC coil resistance.
2. Performance characteristic data are measured at a coil temperature of 23°C.
3. AC coil resistance and impedance are provided as reference values (at 60 Hz).
4. Power consumption drop was measured for the above data. When driving transistors, check leakage current and connect a bleeder
resistor if required.
5. Rated voltage denoted by “*” will be manufactured upon request. Ask your OMRON representative.
Poles Front Mounting
Socket (DIN-track/
screwless clamp
[SLC])
Front-mounting
Socket (DIN-track/
screw mounting)
Back-mounting Socket
Solder terminals Wire-wrap terminals PCB terminals
Without clip With clip Without clip With clip
2 PYF08S PYF08A-E
PYF08A-N
PY08 PY08-Y1 PY08QN
PY08QN2
PY08QN-Y1
PY08QN2-Y1
PY08-02
4 PYF14S PYF14A-E
PYF14A-N
PYF14-ESS
PYF14-ESN
PY14 PY14-Y1 PY14QN
PY14QN2
PY14QN-Y1
PY14QN2-Y1
PY14-02
Relay type Poles Front Mounting Socket
(DIN-track/screwless clamp
[SLC])
Front-connecting Socket (DIN-track/
screw mounting)
Back-connecting Socket
Solder/Wire-wrap terminals PCB terminals
Socket Clip Socket Clip Socket Clip
Without 2-pole
test button
2 PYF08S PYCM-08S PYF08A-E
PYF08A-N
PYC-A1 PY08(QN) PYC-P
PYC-P2
PY08-02 PYC-P
PYC-P2
4 PYF14S PYCM-14S PYF14A-E
PYF14A-N
PY14(QN) PY14-02
PYF14-ESS
PYF14-ESN
PYC0 (metal)
PYC35 (plastic)
2-pole
test button
2 PYF08S PYCM-08S PYF08A-E
PYF08A-N
PYC-E1 PY08(QN) PYC-P2 PY08-02 PYC-P2
Socket model For 1 Socket For 18 Sockets For 36 Sockets
PY08, PY08QN(2), PY14, PY14QN(2) PYP-1 PYP-18 PYP-36
Supporting Track (length = 500 mm) PFP-50N
Supporting Track (length = 1,000 mm) PFP-100N, PFP-100N2
End Plate PFP-M
Spacer PFP-S
Rated voltage Rated current Coil
resistance
Coil inductance
(reference value)
Must
operate
voltage
Must
release
voltage
Max.
voltage
Power
consumption
(approx.)
50 Hz 60 Hz Arm. OFF Arm. ON % of rated voltage
AC 6 V* 214.1 mA 183 mA 12.2 Ω 0.04 H 0.08 H 80% max. 30% min. 110% 1.0 to 1.2 VA
(60 Hz)
12 V 106.5 mA 91 mA 46 Ω 0.17 H 0.33 H
24 V 53.8 mA 46 mA 180 Ω 0.69 H 1.30 H
48/50 V* 24.7/
25.7 mA
21.1/
22.0 mA
788 Ω 3.22 H 5.66 H
110/120 V 9.9/10.8 mA 8.4/9.2 mA 4,430 Ω 19.20 H 32.1 H 0.9 to 1.1 VA
(60 Hz)
220/240 V 4.8/5.3 mA 4.2/4.6 mA 18,790 Ω 83.50 H 136.4 H
DC 6 V* 151 mA 39.8 Ω 0.17 H 0.33 H 10% min. 0.9 W
12 V 75 mA 160 Ω 0.73 H 1.37 H
24 V 37.7 mA 636 Ω 3.20 H 5.72 H
48 V* 18.8 mA 2,560 Ω 10.60 H 21.0 H
100/110 V 9.0/9.9 mA 11,100 Ω 45.60 H 86.2 H
