Omron NB7W-TW00B Service Guide

13
■ Characteristics
*1 NB-V1 does not support printing functions.
When printing the screen, please take a screenshot of the NB-Designer screen and print it.
*2 As to PLCs that can be connected to NB, refer to NB-series Programmable Terminals Host
Connection Manual.
Item
Discontinued Products
NB□□-TW□□B
Recommended Replacements
NB□□-TW□□B -V1
NB3Q
NB5Q
NB7W
NB10W
NB3Q-V1
NB5Q-V1
NB7W-V1
NB10W-V1
00
01
00
01
00
01
01
00
01
00
01
00
01
01
Display
device
TFT LCD
TFT LCD
Resolution
QVGA
320×240
QVGA
320×234
WVGA 800×480
QVGA
320×240
QVGA
320×240
WVGA
800×480
WSVGA
1024×600
Color
65536 colors
65536 colors
Support
software
NB-Designer Ver1.531 less than
NB-Designer Ver1.60 or higher
External
Interfaces
Ethernet ports
(Only NB -TW01B supports),
USB host port,
USB slave port *1,
Serial port (2 ports, 1 port for NB3Q)
Ethernet ports
(Only NB -TW01B-V1 supports),
USB host port,
USB slave port *1,
Serial port (2 ports, 1 port for NB3Q)
External
storage
device
USB Memory Device
(Only for -TW01B)
USB Memory Device
(Only for -TW01B-V1)
Backlight life
50,000 hours min.
50,000 hours min.
Ambient
operating
temperature
0 to 50℃
0 to 50℃
Communicati
ons method
Host Link, Ethernet *2
Host Link, Ethernet *2

Omron NB7W-TW00B Specifications

General

Brand	Omron
Model	NB7W-TW00B
Category	Touch terminals
Language	English
