Section 1 Outline of Macro Function
1-3
NS series Macro Referenc
1-2 Macro Execution Condition
Macros can be created for each project, screen, and functional objects. Also they can be
created for the following execution conditions.
Executing conditions for the project
Macro execution conditions that can be made for the project are indicated below.
Select [PT]-[Project Properties]-[Macro] tab in CX-Designer, then set execution condition and
record macro.
For details on registering macros, refer to the online CX-Designer Help ‘System Settings and
Project Properties’.
Execution condition Explanation
When Loading a Project Execute just before loading the first screen after
starting up NS-Hardware
ON timing Alarm/Event
occurred
Execute when alarm is occurred
ON timing Alarm/Event is
canceled
Execute when alarm is cancelled
When a bit changed Set macro to execute when the address of specified
bit type is changed. Up to 10 macros can be set.
When a value changed Set macro to execute when the address of specified
word type is changed. Up to 10 macros can be set.
Execution conditions for the screen
Macro execution conditions that can be made for each screen are indicated below.
Select [PT]-[Screen/Sheet Properties]-[Macro] tab screen in CX-Designer, then set execution
condition and record macro.
For details on registering macros, refer to the online CX-Designer Help ‘Creating Screens’
Execution condition Explanation
When Loading a Screen Execute immediately after reading screen data to
display the next
When Unloading a Screen Execute immediately after closing the current screen
