20.
Do not install the units in any of the following locations :
•
Locations subject to rapid changes in temperature
•
Locations subject to temperatures or humidities outside the
range specified in the specification
•
Locations subject to condensation as the result of high
humidity
•
Locations subject splashing chemicals or solvents
•
Locations subject to oil splashes
•
Locations subject to corrosive or flammable gases
•
Locations subject to strong shock or vibration
•
Locations outdoors subject to direct wind and rain
•
Locations subject to strong ultraviolet light
21.
Take appropriate and sufficient countermeasures when installing
systems in the following locations :
•
Locations subject to static elctricity or other forms of noise
•
Locations subject to strong electromagnetic or magnetic fields
•
Locations subject to possible exposure to radioactivity
22.
The whole system may stop, depending on how the power supply is
turned ON or OFF. Turn ONor OFF the power supply according to the
specified procedure.
Page 7
Page 14
Page 5
Page 16
Pin Connections
Following are the PLC port pin designations for
NT2S-SF123B-EV2
:
PLC port pin # Designation
2, 3, 5 GND
4 VCC (+5V)
6 TXD (Transmit CMOS)
7 RXD (Receive CMOS)
1, 8, 9 N C
Triggering screens
As can be seen from the above examples, there are two ways to display
screens with the
NT2S-SF123B-EV2
:
1. Keep all the message characters in the data memory ( the Omron
PLCs have lot of data registers which in most applications involving
simple digital controls are not used anyway ) and simply change the
offset register to display different screens.
The user can fill the data memory using the “data display editor” menu of
the PLC programming software.
2. Note that the data memory as well as the program memory can be
used for embedding of data.
Of course, a combination of the two methods can be used to
optimize the memory usage.
OMRON
OMRON Corporation
System Components Division
66 Matsumoto
Mishima-city, Shizuoka 411-8511
Japan.
Tel : (81) 559-77-9633 / Fax : (81) 559-77-9097
Regional Headquarters
OMRON EUROPE B.V.
Wegalaan 67-69, NL-2132 JD Hoofddorp
The Netherlands
Tel : (31) 2356-81-300 / Fax : (31) 2356-81-388
OMRON ELECTRONICS, INC.
1 East Commerce Drive, Schaumburg, IL 60173
U.S.A.
Tel : (1) 847-843-7900 / Tel : (1) 847-843-8568
OMRON ASIA PACIFIC PTE. LTD.
83 Clemenceau Avenue,
#11-01, UE Square,
Singapore 239920
Tel : (65) 835-3011 / Tel : (65) 835-2711
Note : Specifications subject to change without notice.
Printed in India.
