Omron NX-EC0222 User Manual

A - 33
Appendices
NX-series Position Interface Units User’s Manual (W524)
A-2 Object Lists
A
A-2-2 Incremental Encoder Input Units
• The value latched by latch input 1 through an external input or phase-Z signal is displayed.
• The value latched by latch input 2 through an external input or phase-Z signal is displayed.
• The value latched by the internal latch is displayed.
*1. This bit changes according to the setting of the Latch Input 1 Enable bit for latching. Refer to Latch
Function on page 6-41 for information on latching.
*2. This bit is cleared when the Latch Input 1 Enable bit changes from 1 to 0.
*3. This bit changes according to the setting of the Latch Input 2 Enable bit for latching. Refer to Latch
Function on page 6-41 for information on latching.
*4. This bit is cleared when the Latch Input 2 Enable bit changes from 1 to 0.
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
6005 --- Latch Input 1 Data --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-EC0112, NX-EC0122, NX-EC0132, or NX-EC0142 are 1. The values for the NX-EC0212 or
NX-EC0222 are 2.
*1 --- USINT RO No ---
01 Ch1 Latch Input 1 Data 0 −2147483648 to
2147483647
--- DINT RO Yes ---
02
Ch2 Latch Input 1 Data
*2
*2. This object does not exist on the NX-EC0112, NX-EC0122, NX-EC0132, and NX-EC0142.
0 −2147483648 to
2147483647
--- DINT RO Yes ---
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
6006 --- Latch Input 2 Data --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-EC0112, NX-EC0122, NX-EC0132, or NX-EC0142 are 1. The values for the NX-EC0212 or
NX-EC0222 are 2.
*1 --- USINT RO No ---
01 Ch1 Latch Input 2 Data 0 −2147483648 to
2147483647
--- DINT RO Yes ---
02
Ch2 Latch Input 2 Data
*2
*2. This object does not exist on the NX-EC0112, NX-EC0122, NX-EC0132, and NX-EC0142.
0 −2147483648 to
2147483647
--- DINT RO Yes ---
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
6007 --- Internal Latch Data --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-EC0112, NX-EC0122, NX-EC0132, or NX-EC0142 are 1. The values for the NX-EC0212 or
NX-EC0222 are 2.
*1 --- USINT RO No ---
01 Ch1 Internal Latch Data 0 −2147483648 to
2147483647
--- DINT RO Yes ---
02 Ch2 Internal Latch Data
*2
*2. This object does not exist on the NX-EC0112, NX-EC0122, NX-EC0132, and NX-EC0142.
0 −2147483648 to
2147483647
--- DINT RO Yes ---
