Omron R88D-KN30F-ECT-L User Manual

4 System Design
4 - 28
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
Unit Details
*1 A specified combination of Servo Drive and Servomotor must be used.
z Cable Details
Symbol Name Manufacturer Model Comment
SG Surge absorber Okaya Electric Industries
Co., Ltd.
R·A·V-801BXZ-4 –
NF Noise filter Schaffner EMC Inc. FN258L-16-07 3-phase 400 VAC (16 A)
FN258L-30-07 3-phase 400 VAC (30 A)
SD Servo Drive OMRON – *1
SM Servomotor OMRON – *1
FC1 Clamp core TDK ZCAT3035-1330
FC2 Clamp core Konno Industry RJ8035
FC3 Clamp core NEC TOKIN Corporation ESD-SR-250
TB Switch box – –
– Controller – – –
Symbol Supplies from Connects to Cable name Length Comment Shielded Ferrite
(1) AC power supply Noise filter Power supply
line
2 m – No No
(2) Noise filter Servo Drive Power supply
line
2 m – No Yes
(3) Servo Drive Servomotor Power cable 20 m – No Yes
(4) Servo Drive Servomotor External
encoder
cable
20 m – Yes Yes
(5) Switch box Servo Drive I/O cable 2 m – No Yes
(6) Frame ground Noise filter FG line 1.5 m – No No
(7) Frame ground Noise filter FG line 1.5 m – No No
(8) AC power supply Controller Power supply
line
1.5 m – No No
