Omron R88D-KN20F-ECT-R

Questions and Answers:

J
Judith MurrayAug 18, 2025
What to do if Omron R88D-KN20F-ECT-R Servo Drives are overloaded?
- C
  cynthiawalkerAug 19, 2025
  If you're encountering an overload with your Omron Servo Drives, it means the feedback value for torque command exceeds the overload level specified in the Overload Detection Level Setting (3512 hex). Check if torque (current) waveforms oscillate or excessively oscillate vertically during analog output or communications. Review the overload warning display and the load rate through communications. You can increase the capacities of the Servo Drive and the Servomotor, set longer acceleration and deceleration times, and reduce the load. Alternatively, try readjusting the gain.
T
Terrance BaileyAug 22, 2025
Why do Omron Servo Drives overheat?
- J
  johnfieldsAug 22, 2025
  If your Omron Servo Drives are overheating, it's because the temperature of the Servo Drive radiator or power elements exceeded the specified value. To resolve this, improve the ambient temperature and the cooling conditions of the Servo Drive. Also, consider increasing the capacities of the Servo Drive and the Servomotor, setting longer acceleration and deceleration times, and reducing the load.
S
Sarah SimonAug 25, 2025
What causes overvoltage in Omron Servo Drives?
- C
  Carol CareyAug 26, 2025
  An overvoltage in Omron Servo Drives occurs when the power supply voltage exceeds the allowable input voltage range. To address this, measure the voltage between the connector (L1, L2, and L3) lines and input the correct voltage. Remove the phase advance capacitor. Use a tester to measure the resistance of the external resistor between the B1 and B2 terminals on the Servo Drive; if the resistance is infinite, the wiring is broken, so replace the external resistor. You might also need to change the regeneration resistance and wattage to the specified values by calculating the regenerative energy and connecting an External Regeneration Resistor with the required regeneration absorption capacity and reducing the descent speed. If all else fails, replace the Servo Drive.
M
Matthew MillerAug 27, 2025
Why Omron Servo Drives show main circuit power supply undervoltage?
- C
  Corey FitzpatrickAug 28, 2025
  If you're experiencing a main circuit power supply undervoltage with your Omron Servo Drives, it could be due to a momentary power interruption between L1 and L3 for longer than the value specified for the Momentary Hold Time (3509 hex), or the voltage between the positive and negative terminals in the main power supply converter dropped below the specified value while the servo was ON. Measure the voltage between the connector (L1, L2, and L3) lines. Increase the power supply voltage, or change the power supply. Eliminate the cause of the failure of the electromagnetic contactor on the main circuit power supply, and then turn ON the power again. Check the setting of the Momentary Hold Time (3509 hex). Set each phase of the power supply correctly. Increase the power supply capacity.
P
pattywrightAug 31, 2025
What to do for error counter overflow in Omron Servo Drives?
- M
  Michael DavisAug 31, 2025
  If you're seeing an error counter overflow with your Omron Servo Drives, it means position error pulses exceeded the setting of the Following Error Window (6065 hex). Check to see if the Servomotor rotates according to the position command pulse. Check on the torque monitor to see if the output torque is saturated. Adjust the gain. Maximize the set values on the Positive torque limit value (60E0 hex) and the Negative torque limit value (60E1 hex). Wire the encoder as shown in the wiring diagram. Lengthen the acceleration and deceleration times. Reduce the load and speed. Increase the set value of object 6065 hex.
R
rhughesSep 3, 2025
What causes control power supply undervoltage in Omron R88D-KN20F-ECT-R Servo Drives?
- D
  davidrivasSep 3, 2025
  A control power supply undervoltage in Omron Servo Drives indicates that the voltage between the positive and negative terminals in the control power supply converter dropped below the specified value. Measure the voltage between the L1C and L2C lines on the connectors and the terminal block. Increase the power supply voltage, change the power supply, increase the power supply capacity, or replace the Servo Drive.
P
Patricia RivasSep 5, 2025
How to fix encoder communication error in Omron R88D-KN20F-ECT-R Servo Drives?
- C
  Curtis HillSep 5, 2025
  If you're experiencing an encoder communications error with your Omron Servo Drives, it's likely due to noise affecting the data from the encoder. To fix this, provide the required encoder power supply voltage 5 VDC ±5% (4.75 to 5.25 V), paying special attention when the encoder cable is long. If the Servomotor cable and the encoder cable are bundled together, separate them. Also, connect the shield to FG.
K
Karen ReyesSep 8, 2025
What does excessive hybrid deviation error mean for Omron R88D-KN20F-ECT-R Servo Drives?
- C
  Carl SpencerSep 9, 2025
  If you're getting an excessive hybrid deviation error on your Omron Servo Drives, it means that during fully-closed control, the difference between the load position from the external encoder and the Servomotor position from the encoder was larger than the number of pulses set as the Hybrid Following Error Counter Overflow Level (3328 hex). Check the Servomotor and load connection. Check the external encoder and Servo Drive connection. When moving the load, check to see if the change in the Servomotor position (encoder feedback value) has the same sign as the change in the load position (external encoder feedback value).
T
Tiffany RobinsonSep 12, 2025
What causes encoder communication disconnection error in Omron Servo Drives?
- S
  stevensshelleySep 12, 2025
  If you encounter an encoder communications disconnection error with Omron Servo Drives, it means a disconnection was detected because communications between the encoder and the Servo Drive were stopped more frequently than the specified value. To resolve this, wire the encoder correctly as shown in the wiring diagram and correct the connector pin connections.

Omron R88D-KN20F-ECT-R Specifications

General

Brand	Omron
Model	R88D-KN20F-ECT-R
Category	Servo Drives
Language	English

Summary

Terms and Conditions Agreement

Exclusive Warranty

Details Omron's warranty coverage for defects in materials and workmanship.

Limitations

Buyer Remedy

Limitation on Liability; Etc

Safety Precautions

Definition of Precautionary Information

Explains the meaning of safety precautions and symbols used throughout the manual.

Precautions for Safe Use

Provides critical safety guidelines for installation, operation, and maintenance to prevent hazards.

Installation and Wiring

Details essential precautions for safe installation and wiring procedures.

Operation and Adjustment

Covers safety aspects during operation and adjustment phases.

Maintenance and Inspection

Models and External Dimensions

2-3 Model Tables

2-4 External and Mounting Dimensions

Provides external dimensions and mounting dimensions for Servo Drives and Servomotors.

Specifications

3-1 Servo Drive Specifications

Provides general specifications, characteristics, and international standards for Servo Drives.

3-2 Overload Characteristics (Electronic Thermal Function)

Explains the overload protection function and provides overload characteristics graphs.

3-3 Servomotor Specifications

Details general specifications and characteristics for OMNUC G5-Series AC Servomotors.

System Design

4-1 Installation Conditions

Explains installation conditions for Servo Drives and Servomotors, including environment and mechanical connections.

4-2 Wiring

Provides wiring diagrams for peripheral equipment connection examples.

4-3 Wiring Conforming to EMC Directives

Details wiring requirements for EMC Directive conformance.

4-4 Regenerative Energy Absorption

Drive Profile

6-1 Controlling the State Machine of the Servo Drive

Explains how the state of OMNUC G5-series Servo Drives is controlled via Controlword and Statusword.

6-2 Modes of Operation

6-3 Cyclic Synchronous Position Mode

Describes position control using target position and cyclic synchronization.

6-4 Torque Limit

6-6 Fully-closed Control

Describes using an external encoder for direct position detection and feedback for accurate positioning.

6-7 Object Dictionary

Applied Functions

7-1 Sequence IO Signals

Explains how to set sequences and allocate input/output signal functions.

7-5 Brake Interlock

7-8 Gain Switching Function

Switches position loop and speed loop gain based on conditions like load inertia or speed.

Safety Function

8-1 Safe Torque OFF Function

Explains the STO function for cutting off motor current and stopping the motor via safety device signals.

Details on Servo Parameter Objects

9-1 Basic Settings

9-2 Gain Settings

Explains gain adjustment procedures, including automatic and manual tuning methods.

9-3 Vibration Suppression Settings

Operation

10-1 Operational Procedure

Provides a step-by-step guide for operating the motor and drive after installation and wiring.

10-2 Preparing for Operation

Details items to check before turning ON power, including supply voltage and wiring.

10-3 Trial Operation

Explains procedures for performing trial operation to confirm servo system correctness.

Adjustment Functions

11-1 Analog Monitor

11-2 Gain Adjustment

Explains gain adjustment using realtime autotuning or manual tuning for optimal responsiveness.

11-3 Realtime Autotuning

Details the automatic gain adjustment process based on machine rigidity and load inertia.

11-4 Manual Tuning

Provides procedures for manual tuning when autotuning does not achieve desired responsiveness.

11-11 Feed-forward Function

Troubleshooting and Maintenance

12-1 Troubleshooting

Provides preliminary checks and analytical software for determining problem causes.

12-2 Warnings

12-3 Errors

Details error output, power circuit control, and error number display on the front panel.

12-4 Troubleshooting

Guides on determining error conditions and taking appropriate measures.

12-5 Periodic Maintenance
