4-4 Noise Reduction
4
4-4-2 Selecting Connection Components
Use the following noise filter for the brake power supply.
Noise can also be reduced by 1.5 turns with the ZCAT3035-1330 (TDK) Clamp Core.
Use one of the following filters to prevent switching noise of PWM of the Servo Drive and to prevent
noise emitted from the internal clock circuit.
*1 Generally used for 1.5 kW or higher.
*2 Generally used for 1.5 kW or lower. The maximum number of windings is 3 turns.
*3 Generally used for 100 W. The maximum number of windings is 2 turns.
*4 Also used on the Drive output power lines to comply with the EMC Directives. Only a clamp is used.
This clamp can also be used to reduce noise current on a FG line.
Noise Filter for the Brake Power Supply
Model
Rated
current
Rated
voltage
Leakage current Manufacturer
SUP-EK5-ER-6 5 A 250 V 1.0 mA
(at 250 Vrms, 60 Hz)
Okaya Electric
Industries Co., Ltd.
Radio Noise Filter and Emission Noise Prevention Clamp Core
Model Manufacturer Application
3G3AX-ZCL1
*1
OMRON For Drive output and power cable
3G3AX-ZCL2
*2
OMRON For Drive output and power cable
ESD-R-47B
*3
NEC TOKIN Corporation For Drive output and power cable
ZCAT3035-1330
*4
TDK For External encoder and I/O cable
