Appendices

A - 40

G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications

• This object gives the mapping for an application that uses only cyclic synchronous position mode

(csp).

• Touch probe status is available.

• The following objects are mapped.

1B01 hex

258th transmit PDO Mapping

Sub-index 00 hex Number of objects in this PDO

Setting

range

–

Unit

–

Default

setting

09 hex Data

attribute

–

Size 1 byte (U8) Access RO PDO map Not possible

Sub-index 01 hex PDO entry 1 (1st Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

603F 0010 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 02 hex PDO entry 2 (2nd Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

6041 0010 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 03 hex PDO entry 3 (3rd Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

6064 0020 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 04 hex PDO entry 4 (4th Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

6077 0010 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 05 hex PDO entry 5 (5th Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

60F4 0020 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 06 hex PDO entry 6 (6th Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

60B9 0010 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 07 hex PDO entry 7 (7th Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

60BA 0020 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 08 hex PDO entry 8 (8th Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

60BC 0020 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Sub-index 09 hex PDO entry 9 (9th Input Object to be mapped)

Setting

range

–

Unit

–

Default

setting

60FD 0020 hex Data

attribute

–

Size 4 bytes (U32) Access RO PDO map Not possible

Error code (603F hex) Torque actual value (6077 hex)

Touch probe pos1 pos value (60BA hex)

Statusword (6041 hex)

Following Error Actual Value (60F4 hex)

Touch probe pos2 pos value (60BC hex)

Position actual value (6064 hex) Touch probe status (60B9 hex) Digital inputs (60FD hex)
